Model DGS-3000-52XEAN 790069429637

93 specifications

Overview

Brand: D-Link
Category: Network Switch
Model: DGS-3000-52X
Part number: DGS-3000-52X
EAN / UPC: 790069429637
Also known as: D-Link DGS-3000-52X network switch Managed L2 Gigabit Ethernet (10/100/1000) 1U Black

93 specifications in 15 groups

Specification	Value
Switch type	Managed
Switch layer	L2
Quality of Service (QoS) support	Yes
Web-based management	Yes
ARP inspection	Yes

Specification	Value
Basic switching RJ-45 Ethernet ports quantity	48
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Installed SFP modules quantity	0
Installed SFP+ modules quantity	0
SFP+ module slots quantity	4
Fiber optic connector	SFP+
Console port	RJ-45

Specification	Value
Networking standards	IEEE 802.1AX, IEEE 802.1D, IEEE 802.1ag, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3ah, IEEE 802.3u, IEEE 802.3x
10G support	Yes
Copper ethernet cabling technology	10BASE-T, 100BASE-TX, 1000BASE-T
Cable types supported	Cat5, Cat5e
Port mirroring	Yes
Full duplex	Yes
Auto MDI/MDI-X	Yes
Auto-negotiation	Yes
Broadcast storm control	Yes
Flow control support	Yes
Head-of-line (HOL) blocking	Yes
Link aggregation	Yes
Spanning tree protocol	Yes
VLAN support	Yes
Virtual LAN features	Private VLAN, Voice VLAN, Tagged VLAN, MAC address-based VLAN, Port-based VLAN
Number of VLANs	4094

Specification	Value
DHCP features	DHCP server, DHCP client
Access Control List (ACL)	Yes
Access Control List (ACL) rules	1024
IGMP snooping	Yes
Authentication	Guest VLAN, MAC-based authentication, Port-based authentication, Web-based authentication
BPDU filtering/protection	Yes
IP-MAC-Port binding	Yes
SSH/SSL support	Yes
Security algorithms	802.1x RADIUS, SNMP, SNMPv3, SSH, SSH-2, SSL/TLS

Specification	Value
Multicast support	Yes
Multicast Listener Discovery (MLD) snooping	MLD v1, MLD v2

Specification	Value
Rack mounting	Yes
Stackable	Yes
Form factor	1U
Product colour	Black
LED indicators	Activity, Fan fail, Link, Power, Speed
Number of fans	2 fan(s)
Safety	cUL, CB

Specification	Value
Virtual stacking (units)	32
Built-in processor	Yes
Noise level	45.9 dB
Mean time between failures (MTBF)	465240 h

Specification	Value
Redundant power supply (RPS) support	Yes
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	40.7 W
Surge protection voltage	6 kV

Specification	Value
Power over Ethernet (PoE)	No

Specification	Value
Operating temperature (T-T)	-5 - 50 °C
Storage temperature (T-T)	-20 - 70 °C
Operating relative humidity (H-H)	0 - 95%
Storage relative humidity (H-H)	0 - 95%
Heat dissipation	145.948 BTU/h

Specification	Value
Master (outer) cases per pallet (air)	24 pc(s)
Master (outer) cases per pallet (sea)	24 pc(s)
Pallet gross length	110 cm
Pallet gross weight (air)	318.3 kg
Pallet gross weight (sea)	318.3 kg
Pallet gross width	120 cm
Pallet height (air)	173 cm
Pallet height (sea)	173 cm
Products per pallet (air)	72 pc(s)
Products per pallet (sea)	72 pc(s)
Products per shipping (inner) case	3 pc(s)
Shipping (inner) case gross weight	12.5 kg
Shipping (inner) case height	39.8 cm
Shipping (inner) case length	57.3 cm
Shipping (inner) case net weight	7.25 kg
Shipping (inner) case width	32.4 cm

Specification	Value
Certification	CE, FCC, C-Tick, VCCI, BSMI
