1000) Power over Ethernet (PoE) 1U Black

Model DGS-3000-28LPEAN 790069429583

88 specifications

Noise47.4 dB
Type1U
Weight2.54 kg
ColourBlack
Switch typeManaged
Basic switching RJ-45 Ethernet ports quantity24

See all specifications

Overview

Noise: 47.4 dB
Type: 1U
Weight: 2.54 kg
Colour: Black
Switch type: Managed
Basic switching RJ-45 Ethernet ports quantity: 24

Brand: D-Link
Category: Network Switch
Model: DGS-3000-28LP
Part number: DGS-3000-28LP
EAN / UPC: 790069429583
Also known as: D-Link DGS-3000-28LP network switch Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) 1U Black

Specifications

88 specifications in 15 groups

Management features

Specification	Value
Switch type	Managed
Switch layer	L2
Quality of Service (QoS) support	Yes
Web-based management	Yes
ARP inspection	Yes

Ports & interfaces

Specification	Value
Basic switching RJ-45 Ethernet ports quantity	24
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Installed SFP modules quantity	0
Installed SFP+ modules quantity	0
SFP module slots quantity	4
Console port	RJ-45

Network

Specification	Value
Networking standards	IEEE 802.1AX, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1ag, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
10G support	Yes
Copper ethernet cabling technology	10BASE-T, 100BASE-TX, 1000BASE-T
Cable types supported	Cat5, Cat5e
Port mirroring	Yes
Full duplex	Yes
Auto MDI/MDI-X	Yes
Flow control support	Yes
Head-of-line (HOL) blocking	Yes
Link aggregation	Yes
Spanning tree protocol	Yes
VLAN support	Yes
Virtual LAN features	Private VLAN, Voice VLAN, Tagged VLAN, Protocol-based VLAN, MAC address-based VLAN, Port-based VLAN
Number of VLANs	4094

Data transmission

Specification	Value
MAC address table	16000 entries
Switching capacity	56 Gbit/s
Forwarding rate	68.45 Mpps
Number of static routes	64
Jumbo frames support	Yes
Jumbo frames	9216
Packet buffer memory	1.5 MB

Security

Specification	Value
DHCP features	DHCP server, DHCP client
Access Control List (ACL)	Yes
Access Control List (ACL) rules	1024
IGMP snooping	Yes
BPDU filtering/protection	Yes
Security algorithms	802.1x RADIUS, SNMP, SNMPv3, SSH, SSH-2, SSL/TLS

Multicast features

Specification	Value
Multicast support	Yes
Multicast Listener Discovery (MLD) snooping	MLD v1, MLD v2

Design

Specification	Value
Rack mounting	Yes
Stackable	Yes
Form factor	1U
Product colour	Black
LED indicators	Activity, Fan fail, Link, Power, Speed
Number of fans	2 fan(s)
Safety	cUL, CB
Electromagnetic compatibility	CE, FCC, C-Tick, VCCI, BSMI

Performance

Specification	Value
Virtual stacking (units)	32
Built-in processor	Yes
Noise level	47.4 dB
Mean time between failures (MTBF)	304565 h

Power

Specification	Value
Redundant power supply (RPS) support	Yes
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	28.4 W
Power consumption (max)	246.5 W

Power over Ethernet (PoE)

Specification	Value
Power over Ethernet (PoE)	Yes
Power over Ethernet plus (PoE+) ports quantity	24
Total Power over Ethernet (PoE) budget	193 W

Operational conditions

Specification	Value
Operating temperature (T-T)	-5 - 50 °C
Operating relative humidity (H-H)	0 - 95%
Heat dissipation	840 BTU/h

Weight & dimensions

Specification	Value
Width	440 mm
Depth	210 mm
Height	44 mm
Weight	2.54 kg

Packaging data

Specification	Value
Package width	348 mm
Package depth	511 mm
Package height	91 mm
Package weight	4.11 kg

Technical details

Specification	Value
Master (outer) cases per pallet (air)	40 pc(s)
Master (outer) cases per pallet (sea)	40 pc(s)
Pallet gross length	110 cm
Pallet gross weight (air)	545.3 kg
Pallet gross weight (sea)	545.3 kg
Pallet gross width	120 cm
Pallet height (air)	2.05 m
Pallet height (sea)	2.05 m
Products per pallet (air)	120 pc(s)
Products per pallet (sea)	120 pc(s)
Products per shipping (inner) case	3 pc(s)
Shipping (inner) case gross weight	13.2 kg
Shipping (inner) case height	38.3 cm
Shipping (inner) case length	52.9 cm
Shipping (inner) case net weight	7.8 kg
Shipping (inner) case width	29.6 cm

Logistics data

Specification	Value
Harmonized System (HS) code	85176990
