52-Port Gigabit Stackable POE Smart Managed Switch including
4 x 10G SFP+
Model DGS-1510-52XMPPart no. DGS-1510-52XMP/EEAN 790069467967
47 specifications
- Noise56.9 dB
- Weight5.41 kg
- ColourBlack
- Switch typeManaged
- Basic switching RJ-45 Ethernet ports quantity48
- 10G supportYes
Overview
- Noise
- 56.9 dB
- Weight
- 5.41 kg
- Colour
- Black
- Switch type
- Managed
- Basic switching RJ-45 Ethernet ports quantity
- 48
- 10G support
- Yes
- Brand
- D-Link
- Category
- Network Switch
- Model
- DGS-1510-52XMP
- Part number
- DGS-1510-52XMP/E
- EAN / UPC
- 790069467967, 5704174940524
- Also known as
- D-Link 52-Port Gigabit Stackable POE Smart Managed Switch including 4 x 10G SFP+
Specifications
47 specifications in 13 groups
Management features
| Specification | Value |
|---|---|
| Switch type | Managed |
| Switch layer | L3 |
| Quality of Service (QoS) support | Yes |
| Web-based management | Yes |
| ARP inspection | Yes |
| Traffic classification | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Basic switching RJ-45 Ethernet ports quantity | 48 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| SFP+ module slots quantity | 4 |
Network
| Specification | Value |
|---|---|
| Networking standards | IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x |
| 10G support | Yes |
| Cable types supported | Cat5, Cat5e |
| Full duplex | Yes |
| Auto MDI/MDI-X | Yes |
Data transmission
| Specification | Value |
|---|---|
| MAC address table | 16000 entries |
| Switching capacity | 128 Gbit/s |
| Throughput | 95.24 Mpps |
| Number of IP interfaces | 16 |
| Jumbo frames support | Yes |
| Jumbo frames | 9216 |
Multicast features
| Specification | Value |
|---|---|
| Multicast support | Yes |
| Multicast MAC address table | 512 entries |
Design
| Specification | Value |
|---|---|
| Rack mounting | Yes |
| Stackable | Yes |
| Product colour | Black |
| Reset button | Yes |
| LED indicators | Activity, Link, PoE, Speed |
| Number of fans | 3 fan(s) |
Performance
| Specification | Value |
|---|---|
| Noise level | 56.9 dB |
Power
| Specification | Value |
|---|---|
| Power supply included | Yes |
| AC input voltage | 100 - 240 V |
| Power consumption (max) | 486.9 W |
Power over Ethernet (PoE)
| Specification | Value |
|---|---|
| Power over Ethernet (PoE) | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -5 - 50 °C |
| Storage temperature (T-T) | -20 - 70 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Heat dissipation | 138.787 BTU/h |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 440 mm |
| Depth | 308 mm |
| Height | 44 mm |
| Weight | 5.41 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 475 mm |
| Package depth | 520 mm |
| Package height | 110 mm |
| Package weight | 7.26 kg |
Certificates
| Specification | Value |
|---|---|
| Certification | CE FCC C-Tick VCCI BSMI cUL CB |
