D-Link DGS-1210-10P/ME/E network switch Managed L2/L3 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black, Grey

DGS-1210-10P/ME/E network switch Managed L2/L3 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black, Grey

Model DGS-1210-10P/ME/E

75 specifications

Memory256 MB
Noise0 dB
Weight1.92 kg
ColourBlack, Grey
Switch typeManaged
Basic switching RJ-45 Ethernet ports quantity8

See all specifications

Overview

Memory: 256 MB
Noise: 0 dB
Weight: 1.92 kg
Colour: Black, Grey
Switch type: Managed
Basic switching RJ-45 Ethernet ports quantity: 8

Brand: D-Link
Category: Network Switch
Model: DGS-1210-10P/ME/E
Part number: DGS-1210-10P/ME/E
Also known as: D-Link DGS-1210-10P/ME/E network switch Managed L2/L3 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black, Grey

Specifications

75 specifications in 14 groups

Management features

Specification	Value
Switch type	Managed
Switch layer	L2/L3
Quality of Service (QoS) support	Yes
Web-based management	Yes
ARP inspection	Yes
System event log	Yes
MIB support	RFC1212, RFC1213, RFC1215, RFC1493, RFC1157, RFC2573, RFC2575, RFC2576, RFC1442, RFC1901, RFC1902, RFC1903, RFC1904, RFC1905, FC1906, RFC1907, RFC1908, RFC2578, RFC3418, RFC271, RFC1757, RFC2819, RFC2021, RFC1398, RFC1643, RFC1650, RFC2358, RFC2665, RFC2674, RFC2618, RFC4022, RFC4113, RFC2389, RFC26

Ports & interfaces

Specification	Value
Basic switching RJ-45 Ethernet ports quantity	8
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Installed SFP modules quantity	0
Installed SFP+ modules quantity	0
SFP module slots quantity	2
Fiber optic connector	SFP
Console port	RJ-45

Network

Specification	Value
Networking standards	IEEE 802.1D, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G support	No
Copper ethernet cabling technology	10BASE-T, 100BASE-TX, 1000BASE-T
Cable types supported	Cat5, Cat5e
Port mirroring	Yes
Full duplex	Yes
Auto MDI/MDI-X	Yes
Auto-negotiation	Yes
Broadcast storm control	Yes
Flow control support	Yes
Head-of-line (HOL) blocking	Yes
Link aggregation	Yes
Spanning tree protocol	Yes
VLAN support	Yes
Number of VLANs	4094

Optical fiber

Specification	Value
Fiber ethernet cabling technology	1000BASE-X

Data transmission

Specification	Value
MAC address table	16000 entries
Switching capacity	20 Gbit/s
Forwarding rate	14.88 Mpps
Store-and-forward	Yes
Jumbo frames support	Yes
Jumbo frames	10000
Packet buffer memory	1.5 MB

Security

Specification	Value
DHCP features	DHCP server, DHCP relay, DHCP client
Access Control List (ACL)	Yes
Access Control List (ACL) rules	768
IGMP snooping	Yes
DoS attack prevention	Yes
IP-MAC-Port binding	Yes
Loop protection	Yes
Password protection	Yes
SSH/SSL support	Yes
Security algorithms	802.1x RADIUS, EAP, LEAP, MD5, PEAP, SNMP, SNMPv3, SSH-2, SSL/TLS, TTLS, WPA2-EAP

Multicast features

Specification	Value
Multicast support	Yes

Design

Specification	Value
Product colour	Black, Grey
LED indicators	Activity, Fan fail, Link, Power, Speed
Safety	CE, LVD, UL, CB

Performance

Specification	Value
Memory type	DDR3-SDRAM
Internal memory	256 MB
Flash memory	32 MB
Firmware upgradeable	Yes
Maximum cable length	100 m
Noise level	0 dB
Mean time between failures (MTBF)	315336 h

Power

Specification	Value
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	101.7 W
Surge protection	Yes

Power over Ethernet (PoE)

Specification	Value
Power over Ethernet (PoE)	Yes
Power over Ethernet plus (PoE+) ports quantity	8
Total Power over Ethernet (PoE) budget	78 W

Operational conditions

Specification	Value
Operating temperature (T-T)	-5 - 50 °C
Storage temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	10 - 90%
Storage relative humidity (H-H)	5 - 90%
Heat dissipation	307.7 BTU/h

Weight & dimensions

Specification	Value
Width	280 mm
Depth	180 mm
Height	44 mm
Weight	1.92 kg

Certificates

Specification	Value
Certification	FCC A, CE A, VCCI, BSMI, CCC
