1000) Power over Ethernet (PoE) 1U Black, White

Model DGS-1100-26MPPEAN 790069420153

66 specifications

Type1U
Weight3.9 kg
ColourBlack, White
Switch typeManaged
Basic switching RJ-45 Ethernet ports quantity24
10G supportNo

See all specifications

Overview

Type: 1U
Weight: 3.9 kg
Colour: Black, White
Switch type: Managed
Basic switching RJ-45 Ethernet ports quantity: 24
10G support: No

Brand: D-Link
Category: Network Switch
Model: DGS-1100-26MPP
Part number: DGS-1100-26MPP
EAN / UPC: 790069420153
Also known as: D-Link DGS-1100-26MPP network switch Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) 1U Black, White

Specifications

66 specifications in 13 groups

Management features

Specification	Value
Switch type	Managed
Switch layer	L2
Quality of Service (QoS) support	Yes
Web-based management	Yes
MIB support	RFC768 UDP, RFC791 IP, RFC792 ICMP, RFC793 TCP, RFC826 ARP, RFC1213 MIB II, RFC1493 Bridage MIB, RFC1907 SNMPv2 MIB, RFC1215 MIB Traps Convention , RFC2233 Interface Group MIB, RFC2665 Ether-like MIB, RFC4363 IEEE 802.1p MIB, ZoneDefense MIB, Private MIB, RFC951 BootP client, RFC1542 BootP/DHCP clie

Ports & interfaces

Specification	Value
Basic switching RJ-45 Ethernet ports quantity	24
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Combo SFP ports quantity	2
Fiber optic connector	SFP

Network

Specification	Value
Networking standards	IEEE 802.1D, IEEE 802.1Qbg, IEEE 802.1p, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3bt, IEEE 802.3u, IEEE 802.3x
10G support	No
Port mirroring	Yes
Full duplex	Yes
Auto MDI/MDI-X	Yes
Auto-negotiation	Yes
Broadcast storm control	Yes
Flow control support	Yes
Head-of-line (HOL) blocking	Yes
Link aggregation	Yes
Rate limiting	Yes
Spanning tree protocol	Yes
VLAN support	Yes
Virtual LAN features	Tagged VLAN, Port-based VLAN

Data transmission

Specification	Value
MAC address table	16000 entries
Switching capacity	52 Gbit/s
Throughput	38.69 Mpps
Number of queues	4
Jumbo frames support	Yes
Jumbo frames	9216
Packet buffer memory	1.5 MB

Security

Specification	Value
DHCP features	DHCP client
IGMP snooping	Yes
Loop protection	Yes
SSH/SSL support	Yes
Security algorithms	SSL/TLS

Multicast features

Specification	Value
Multicast support	Yes
Number of multicast groups filtered	64

Protocols

Specification	Value
Management protocols	SNMPv2, IPv4/IPv6

Design

Specification	Value
Rack mounting	Yes
Form factor	1U
Product colour	Black, White
LED indicators	Yes
Number of fans	2 fan(s)
Safety	cUL, UL, LVD, CB, CCC, BSMI
Electromagnetic compatibility	FCC/IC, CE, VCCI, BSMI, CCC

Performance

Specification	Value
Flash memory	16 MB
Mean time between failures (MTBF)	268289 h

Power

Specification	Value
Power supply included	Yes
Redundant power supply (RPS) support	No
Number of power supply units	1
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	539 W

Power over Ethernet (PoE)

Specification	Value
Power over Ethernet (PoE)	Yes
Power over Ethernet (PoE) ports quantity	24
Power over Ethernet (PoE) power per port	30 W
Total Power over Ethernet (PoE) budget	518 W

Operational conditions

Specification	Value
Operating temperature (T-T)	-5 - 50 °C
Storage temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	0 - 95%
Storage relative humidity (H-H)	0 - 95%
Heat dissipation	2079.35 BTU/h

Weight & dimensions

Specification	Value
Width	440 mm
Depth	290 mm
Height	44 mm
Weight	3.9 kg
