1000) Power over Ethernet (PoE) Black, Grey

Model DGS-1100-10MPPEAN 790069420146

78 specifications

Weight1.98 kg
ColourBlack, Grey
Switch typeManaged
Basic switching RJ-45 Ethernet ports quantity10
10G supportNo
MAC address table16000 entries

See all specifications

Overview

Weight: 1.98 kg
Colour: Black, Grey
Switch type: Managed
Basic switching RJ-45 Ethernet ports quantity: 10
10G support: No
MAC address table: 16000 entries

Brand: D-Link
Category: Network Switch
Model: DGS-1100-10MPP
Part number: DGS-1100-10MPP
EAN / UPC: 790069420146
Also known as: D-Link DGS-1100-10MPP network switch Managed Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black, Grey

Specifications

78 specifications in 14 groups

Management features

Specification	Value
Switch type	Managed
Quality of Service (QoS) support	Yes
Web-based management	Yes
Traffic classification	Yes
MIB support	RFC 768, RFC 791, RFC 792, RFC 826, RFC 1213, RFC 1493, RFC 1907, RFC 1215, RFC 2233, RFC 2665, RFC 951, RFC 1542, RFC 4363, RFC 2236

Ports & interfaces

Specification	Value
Basic switching RJ-45 Ethernet ports quantity	10
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Installed SFP modules quantity	0
Installed SFP+ modules quantity	0
SFP module slots quantity	2
Fiber optic connector	SFP

Network

Specification	Value
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1w, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3x
10G support	No
Copper ethernet cabling technology	10BASE-T, 100BASE-TX, 1000BASE-TX
Port mirroring	Yes
Active link detection	Yes
Broadcast storm control	Yes
Flow control support	Yes
Head-of-line (HOL) blocking	Yes
Link aggregation	Yes
Rate limiting	Yes
Spanning tree protocol	Yes
VLAN support	Yes
Virtual LAN features	Tagged VLAN, Port-based VLAN
Number of VLANs	4094

Data transmission

Specification	Value
MAC address table	16000 entries
Switching capacity	20 Gbit/s
Throughput	14.88 Mpps
Number of trunks	8
Number of queues	4
Jumbo frames support	Yes
Jumbo frames	9216
Packet buffer memory	1.5 MB

Security

Specification	Value
IGMP snooping	Yes
SSH/SSL support	Yes
Security algorithms	SNMP

Multicast features

Specification	Value
Multicast support	Yes
Number of multicast groups filtered	64

Design

Specification	Value
Product colour	Black, Grey
LED indicators	Activity, Link, Power, Speed
Safety	cUL, UL, GS, CB
Electromagnetic compatibility	FCC/IC, CE, VCCI, RCM, BSMI

Performance

Specification	Value
Flash memory	16 MB
Mean time between failures (MTBF)	1719951 h

Power

Specification	Value
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	253 W

Power over Ethernet (PoE)

Specification	Value
Power over Ethernet (PoE)	Yes
Power over Ethernet (PoE) ports quantity	8

Operational conditions

Specification	Value
Operating temperature (T-T)	-5 - 50 °C
Storage temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	0 - 95%
Storage relative humidity (H-H)	0 - 95%
Heat dissipation	1001.12 BTU/h

Weight & dimensions

Specification	Value
Width	280 mm
Depth	180 mm
Height	44 mm
Weight	1.98 kg

Packaging data

Specification	Value
Package width	329 mm
Package depth	358 mm
Package height	102 mm
Package weight	2.97 kg

Technical details

Specification	Value
Master (outer) cases per pallet (air)	45 pc(s)
Master (outer) cases per pallet (sea)	45 pc(s)
Pallet gross length	110 cm
Pallet gross weight (air)	468.7 kg
Pallet gross weight (sea)	468.7 kg
Pallet gross width	120 cm
Pallet height (air)	191.5 cm
Pallet height (sea)	191.5 cm
Products per pallet (air)	135 pc(s)
Products per pallet (sea)	135 pc(s)
Products per shipping (inner) case	3 pc(s)
Shipping (inner) case gross weight	9.86 kg
Shipping (inner) case height	35.6 cm
Shipping (inner) case length	37.4 cm
Shipping (inner) case net weight	8.91 kg
Shipping (inner) case width	32.8 cm
