1000) Power over Ethernet (PoE) Black

Model DGS-1100-05PDEAN 790069428784

68 specifications

Weight380 g
ColourBlack
Switch typeManaged
Basic switching RJ-45 Ethernet ports quantity5
10G supportNo
MAC address table2000 entries

See all specifications

Overview

Weight: 380 g
Colour: Black
Switch type: Managed
Basic switching RJ-45 Ethernet ports quantity: 5
10G support: No
MAC address table: 2000 entries

Brand: D-Link
Category: Network Switch
Model: DGS-1100-05PD
Part number: DGS-1100-05PD
EAN / UPC: 790069428784
Also known as: D-Link DGS-1100-05PD network switch Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black

Specifications

68 specifications in 16 groups

Management features

Specification	Value
Switch type	Managed
Switch layer	L2
Quality of Service (QoS) support	Yes
Web-based management	Yes

Ports & interfaces

Specification	Value
Basic switching RJ-45 Ethernet ports quantity	5
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Installed SFP modules quantity	0
Installed SFP+ modules quantity	0

Network

Specification	Value
Networking standards	IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3u, IEEE 802.3z
10G support	No
Port mirroring	Yes
Broadcast storm control	Yes
Cable length detection	Yes
Flow control support	Yes
VLAN support	Yes
Virtual LAN features	Tagged VLAN, Port-based VLAN

Data transmission

Specification	Value
MAC address table	2000 entries
Switching capacity	10 Gbit/s
Throughput	7.44 Mpps
Number of trunks	4
Number of queues	4
Jumbo frames support	Yes
Jumbo frames	9216
Packet buffer memory	1 MB

Security

Specification	Value
IGMP snooping	Yes
Security algorithms	SNMP

Multicast features

Specification	Value
Multicast support	Yes

Design

Specification	Value
Rack mounting	No
Product colour	Black
LED indicators	Yes
Safety	cUL, CE LVD, CB, BSMI, CCC

Performance

Specification	Value
Flash memory	2 MB
Mean time between failures (MTBF)	2346941 h

Power

Specification	Value
Power consumption (max)	23.92 W

Power over Ethernet (PoE)

Specification	Value
Power over Ethernet (PoE)	Yes
Power over Ethernet (PoE) ports quantity	2
Power over Ethernet (PoE) power per port	15.4 W
Total Power over Ethernet (PoE) budget	18 W

Operational conditions

Specification	Value
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	0 - 90%
Storage relative humidity (H-H)	5 - 95%

Weight & dimensions

Specification	Value
Width	150 mm
Depth	97 mm
Height	28 mm
Weight	380 g

Packaging data

Specification	Value
Package width	139 mm
Package depth	210 mm
Package height	53 mm
Package weight	615 g

Technical details

Specification	Value
Master (outer) cases per pallet (air)	28 pc(s)
Master (outer) cases per pallet (sea)	44 pc(s)
Pallet gross length	110 cm
Pallet gross weight (air)	396.4 kg
Pallet gross weight (sea)	608.9 kg
Pallet gross width	120 cm
Pallet height (air)	132.5 cm
Pallet height (sea)	2 m
Products per pallet (air)	560 pc(s)
Products per pallet (sea)	880 pc(s)
Products per shipping (inner) case	20 pc(s)
Shipping (inner) case gross weight	13.2 kg
Shipping (inner) case height	17 cm
Shipping (inner) case length	56.8 cm
Shipping (inner) case net weight	12.3 kg
Shipping (inner) case width	44.5 cm

Certificates

Specification	Value
Certification	FCC Class B, CE Class B, VCCI Class B, BSMI, CCC

Logistics data

Specification	Value
Harmonized System (HS) code	85176990
