Model DGS-1100-05Part no. DGS-1100-05/EEAN 790069386268

68 specifications

Overview

Brand: D-Link
Category: Network Switch
Model: DGS-1100-05
Part numbers: DGS-1100-05/E, DGS-1100-05/B
EAN / UPC: 790069386268, 790069386251
Also known as: D-Link DGS-1100-05 Managed L2 Gigabit Ethernet (10/100/1000) Grey

68 specifications in 15 groups

Specification	Value
Switch type	Managed
Switch layer	L2
Quality of Service (QoS) support	Yes
Web-based management	Yes

Specification	Value
Basic switching RJ-45 Ethernet ports quantity	5
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Installed SFP modules quantity	0
Installed SFP+ modules quantity	0
Console port	RJ-45
Power connector	DC-in jack

Specification	Value
Networking standards	IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
10G support	No
Port mirroring	Yes
Full duplex	Yes
Auto MDI/MDI-X	Yes
Flow control support	Yes
Link aggregation	Yes
VLAN support	Yes
Virtual LAN features	VLAN Identifier ( VLAN ID), Voice VLAN, Tagged VLAN, Port-based VLAN
Number of VLANs	4094

Specification	Value
IGMP snooping	Yes
MAC address filtering	Yes

Specification	Value
Flash memory	2 MB
Mean time between failures (MTBF)	532838 h

Specification	Value
Power over Ethernet (PoE)	No

Specification	Value
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-10 - 70 °C
Operating relative humidity (H-H)	10 - 95%
Storage relative humidity (H-H)	5 - 95%
Heat dissipation	11.43 BTU/h

Specification	Value
Master (outer) cases per pallet (air)	20 pc(s)
Master (outer) cases per pallet (sea)	32 pc(s)
Pallet gross length	110 cm
Pallet gross weight (air)	284.4 kg
Pallet gross weight (sea)	440.2 kg
Pallet gross width	120 cm
Pallet height (air)	132.5 cm
Pallet height (sea)	2.08 m
Products per pallet (air)	400 pc(s)
Products per pallet (sea)	640 pc(s)
Products per shipping (inner) case	20 pc(s)
Shipping (inner) case gross weight	12.9 kg
Shipping (inner) case height	24.3 cm
Shipping (inner) case length	59.4 cm
Shipping (inner) case net weight	11.8 kg
Shipping (inner) case width	49.2 cm

Specification	Value
Certification	FCC, CE, VCCI

Specification	Value
Harmonized System (HS) code	85176990
