DGS-1016D/E network switch Unmanaged Black, Metallic
Model DGS-1016D/EEAN 5054533077454
53 specifications
- Speed1 Gbit/s
- Weight1.35 kg
- ColourBlack, Metallic
- Switch typeUnmanaged
- Basic switching RJ-45 Ethernet ports quantity16
- 10G supportNo
Overview
- Speed
- 1 Gbit/s
- Weight
- 1.35 kg
- Colour
- Black, Metallic
- Switch type
- Unmanaged
- Basic switching RJ-45 Ethernet ports quantity
- 16
- 10G support
- No
- Brand
- D-Link
- Category
- Network Switch
- Model
- DGS-1016D/E
- Part number
- DGS-1016D/E
- EAN / UPC
- 5054533077454, 616268714391, 644535532720, 777204569076 +16 more
- Also known as
- D-Link DGS-1016D/E network switch Unmanaged Black, Metallic
Specifications
53 specifications in 14 groups
Management features
| Specification | Value |
|---|---|
| Switch type | Unmanaged |
| Quality of Service (QoS) support | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Basic switching RJ-45 Ethernet ports quantity | 16 |
Network
| Specification | Value |
|---|---|
| Networking standards | IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x |
| 10G support | No |
| Copper ethernet cabling technology | 1000BASE-T, 100BASE-T, 10BASE-T |
| Full duplex | Yes |
| Auto MDI/MDI-X | Yes |
| Flow control support | Yes |
Data transmission
| Specification | Value |
|---|---|
| MAC address table | 8000 entries |
| Switching capacity | 32 Gbit/s |
| Store-and-forward | Yes |
| Maximum data transfer rate | 1 Gbit/s |
| Jumbo frames support | Yes |
| Packet buffer memory | 0.340 MB |
Design
| Specification | Value |
|---|---|
| Rack mounting | Yes |
| Stackable | Yes |
| Product colour | Black, Metallic |
| LED indicators | Yes |
Performance
| Specification | Value |
|---|---|
| Mean time between failures (MTBF) | 828109 h |
Power
| Specification | Value |
|---|---|
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Power consumption (typical) | 11.7 W |
Power over Ethernet (PoE)
| Specification | Value |
|---|---|
| Power over Ethernet (PoE) | No |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -10 - 55 °C |
| Operating relative humidity (H-H) | 5 - 95% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 281.9 mm |
| Depth | 180.3 mm |
| Height | 44.5 mm |
| Weight | 1.35 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 180 mm |
| Package depth | 328 mm |
| Package height | 108 mm |
| Package weight | 1.71 kg |
Technical details
| Specification | Value |
|---|---|
| Master (outer) cases per pallet (air) | 30 pc(s) |
| Master (outer) cases per pallet (sea) | 50 pc(s) |
| Pallet gross length | 110 cm |
| Pallet gross weight (air) | 295.7 kg |
| Pallet gross weight (sea) | 480.3 kg |
| Pallet gross width | 120 cm |
| Pallet height (air) | 121.2 cm |
| Pallet height (sea) | 193 cm |
| Products per pallet (air) | 150 pc(s) |
| Products per pallet (sea) | 250 pc(s) |
| Products per shipping (inner) case | 5 pc(s) |
| Shipping (inner) case gross weight | 9.21 kg |
| Shipping (inner) case height | 35.9 cm |
| Shipping (inner) case length | 57.2 cm |
| Shipping (inner) case net weight | 8.54 kg |
| Shipping (inner) case width | 19.7 cm |
Certificates
| Specification | Value |
|---|---|
| Certification | FCC Class A, CE, ICES-003, VCCI, C-Tick, RoHS |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85176990 |
