DES-108 network switch Unmanaged L2 Gigabit Ethernet (10/100/1000) Desktop Black
Model DES-108Part no. DES-108/BEAN 7900693681964
43 specifications
- TypeDesktop
- Weight412 g
- ColourBlack
- Switch typeUnmanaged
- Basic switching RJ-45 Ethernet ports quantity8
- 10G supportYes
Overview
- Type
- Desktop
- Weight
- 412 g
- Colour
- Black
- Switch type
- Unmanaged
- Basic switching RJ-45 Ethernet ports quantity
- 8
- 10G support
- Yes
- Brand
- D-Link
- Category
- Network Switch
- Model
- DES-108
- Part numbers
- DES-108/B, DES-108, DES-108/E
- EAN / UPC
- 7900693681964, 007906936822, 071030031791, 100177356884 +11 more
- Also known as
- D-Link DES-108 network switch Unmanaged L2 Gigabit Ethernet (10/100/1000) Desktop Black
Specifications
43 specifications in 11 groups
Management features
| Specification | Value |
|---|---|
| Switch type | Unmanaged |
| Switch layer | L2 |
| Quality of Service (QoS) support | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Installed SFP modules quantity | 0 |
| Installed SFP+ modules quantity | 0 |
| Power connector | DC-in jack |
Network
| Specification | Value |
|---|---|
| Networking standards | IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x |
| 10G support | Yes |
| Copper ethernet cabling technology | 1000BASE-T, 100BASE-TX, 10BASE-T |
| Full duplex | Yes |
| Auto MDI/MDI-X | Yes |
| Flow control support | Yes |
Data transmission
| Specification | Value |
|---|---|
| MAC address table | 1000 entries |
| Switching capacity | 16 Gbit/s |
| Store-and-forward | Yes |
| Number of queues | 2 |
| Jumbo frames support | Yes |
| Jumbo frames | 1536 |
| Packet buffer memory | 0.768 MB |
Security
| Specification | Value |
|---|---|
| MAC address filtering | Yes |
Design
| Specification | Value |
|---|---|
| Rack mounting | No |
| Form factor | Desktop |
| Product colour | Black |
| Housing material | Metal |
| LED indicators | Link, Power |
Performance
| Specification | Value |
|---|---|
| Mean time between failures (MTBF) | 511323 h |
Power
| Specification | Value |
|---|---|
| Power source | AC |
| Input current | 1 A |
| Input voltage | 5 V |
| Power consumption (typical) | 1 W |
| Power consumption (max) | 4.5 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -10 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 90% |
| Heat dissipation | 17.47 BTU/h |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 162 mm |
| Depth | 102 mm |
| Height | 28 mm |
| Weight | 412 g |
Certificates
| Specification | Value |
|---|---|
| Certification | FCC Class B ICES-003 Class B CE Class B C-Tick Class B VCCI Class B cUL CB |
