DES-105 network switch Unmanaged Black
Model DES-105Part no. DES-105/BEAN 7900693681728
37 specifications
- Speed0.1 Gbit/s
- ConnectivityWired
- Weight265 g
- ColourBlack
- Switch typeUnmanaged
- Basic switching RJ-45 Ethernet ports quantity5
Overview
- Speed
- 0.1 Gbit/s
- Connectivity
- Wired
- Weight
- 265 g
- Colour
- Black
- Switch type
- Unmanaged
- Basic switching RJ-45 Ethernet ports quantity
- 5
- Brand
- D-Link
- Category
- Network Switch
- Model
- DES-105
- Part numbers
- DES-105/B, DES-105, DES-105/E
- EAN / UPC
- 7900693681728, 151903028896, 163120278411, 168141530814 +16 more
- Also known as
- D-Link DES-105 network switch Unmanaged Black
Specifications
37 specifications in 12 groups
Management features
| Specification | Value |
|---|---|
| Switch type | Unmanaged |
| Quality of Service (QoS) support | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Basic switching RJ-45 Ethernet ports quantity | 5 |
| Power connector | DC-in jack |
Network
| Specification | Value |
|---|---|
| Networking standards | IEEE 802.1p, IEEE 802.3, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x |
| Copper ethernet cabling technology | 100BASE-TX, 10BASE-T |
| Full duplex | Yes |
| Auto MDI/MDI-X | Yes |
| Flow control support | Yes |
Data transmission
| Specification | Value |
|---|---|
| MAC address table | 2000 entries |
| Supported data transfer rates | 10/100 Mbps |
| Switching capacity | 1 Gbit/s |
| Store-and-forward | Yes |
| Maximum data transfer rate | 0.1 Gbit/s |
| Jumbo frames support | Yes |
| Packet buffer memory | 0.384 MB |
Security
| Specification | Value |
|---|---|
| MAC address filtering | Yes |
Design
| Specification | Value |
|---|---|
| Rack mounting | No |
| Product colour | Black |
| Housing material | Metal |
| LED indicators | Link, Power, Yes |
Performance
| Specification | Value |
|---|---|
| Mean time between failures (MTBF) | 495709 h |
Power
| Specification | Value |
|---|---|
| Input current | 1 A |
| Input voltage | 5 V |
| Power consumption (typical) | 3.10 W |
Other features
| Specification | Value |
|---|---|
| Data transfer rate | 200 Mbit/s |
| Dimensions (WxDxH) | 100 x 98 x 28 mm |
| Connectivity technology | Wired |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -10 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 90% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 100 mm |
| Depth | 98 mm |
| Height | 28 mm |
| Weight | 265 g |
Certificates
| Specification | Value |
|---|---|
| Certification | RoHS, FCC Class B, ICES-003 Class B, CE Class B, C-Tick Class B, VCCI Class B, cUL, CB |
