D-Link DES-1018MP network switch Unmanaged Fast Ethernet (10/100) Power over Ethernet (PoE) Black
Model DES-1018MPEAN 7900694067446
47 specifications
- Weight2.15 kg
- ColourBlack
- Switch typeUnmanaged
- Basic switching RJ-45 Ethernet ports quantity16
- MAC address table8000 entries
- Rack mountingYes
Overview
- Weight
- 2.15 kg
- Colour
- Black
- Switch type
- Unmanaged
- Basic switching RJ-45 Ethernet ports quantity
- 16
- MAC address table
- 8000 entries
- Rack mounting
- Yes
- Brand
- D-Link
- Category
- Network Switch
- Model
- DES-1018MP
- Part number
- DES-1018MP
- EAN / UPC
- 7900694067446, 790069406744, 790694067440, 804892192191 +2 more
- Also known as
- D-Link DES-1018MP network switch Unmanaged Fast Ethernet (10/100) Power over Ethernet (PoE) Black
Specifications
47 specifications in 13 groups
Management features
| Specification | Value |
|---|---|
| Switch type | Unmanaged |
Ports & interfaces
| Specification | Value |
|---|---|
| Basic switching RJ-45 Ethernet ports quantity | 16 |
| Basic switching RJ-45 Ethernet ports type | Fast Ethernet (10/100) |
| Combo SFP ports quantity | 0 |
| SFP module slots quantity | 2 |
Network
| Specification | Value |
|---|---|
| Networking standards | IEEE 802.3, IEEE 802.3af, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
Data transmission
| Specification | Value |
|---|---|
| MAC address table | 8000 entries |
Design
| Specification | Value |
|---|---|
| Rack mounting | Yes |
| Product colour | Black |
| LED indicators | Activity, Link, Power, Power fail |
| Number of fans | 1 fan(s) |
| Safety | CB, cUL, LVD, CCC, BSMI |
Performance
| Specification | Value |
|---|---|
| Buffer size | 384 KB |
Power
| Specification | Value |
|---|---|
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Power consumption (typical) | 301.6 W |
Power over Ethernet (PoE)
| Specification | Value |
|---|---|
| Power over Ethernet (PoE) | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Heat dissipation | 1029.5 BTU/h |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 280 mm |
| Depth | 210 mm |
| Height | 44 mm |
| Weight | 2.15 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 329 mm |
| Package depth | 358 mm |
| Package height | 102 mm |
| Package weight | 3.19 kg |
Technical details
| Specification | Value |
|---|---|
| Master (outer) cases per pallet (air) | 45 pc(s) |
| Master (outer) cases per pallet (sea) | 45 pc(s) |
| Pallet gross length | 110 cm |
| Pallet gross weight (air) | 498.2 kg |
| Pallet gross weight (sea) | 498.2 kg |
| Pallet gross width | 120 cm |
| Pallet height (air) | 191.5 cm |
| Pallet height (sea) | 191.5 cm |
| Products per pallet (air) | 135 pc(s) |
| Products per pallet (sea) | 135 pc(s) |
| Products per shipping (inner) case | 3 pc(s) |
| Shipping (inner) case gross weight | 10.5 kg |
| Shipping (inner) case height | 35.6 cm |
| Shipping (inner) case length | 37.4 cm |
| Shipping (inner) case net weight | 9.57 kg |
| Shipping (inner) case width | 32.8 cm |
Certificates
| Specification | Value |
|---|---|
| Certification | FCC Class A, CE, CCC, RoHS, VCCI, BSMI, C-Tick |
