5-Port Multi-Gigabit Unmanaged Switch
Model 5-Port Multi-Gigabit Unmanaged SwitchPart no. DMS-105/BEAN 790069469299
22 specifications
- TypeDesktop
- ColourBlack
- Switch typeUnmanaged
- Basic switching RJ-45 Ethernet ports quantity5
- Networking standardsIEEE 802.3az
- MAC address table4000 entries
Overview
- Type
- Desktop
- Colour
- Black
- Switch type
- Unmanaged
- Basic switching RJ-45 Ethernet ports quantity
- 5
- Networking standards
- IEEE 802.3az
- MAC address table
- 4000 entries
- Brand
- D-Link
- Category
- Network Switch
- Model
- 5-Port Multi-Gigabit Unmanaged Switch
- Part number
- DMS-105/B
- EAN / UPC
- 790069469299
- Also known as
- D-Link 5-Port Multi-Gigabit Unmanaged Switch
Specifications
22 specifications in 8 groups
Management features
| Specification | Value |
|---|---|
| Switch type | Unmanaged |
| Quality of Service (QoS) support | Yes |
| Cloud-managed | No |
| Web-based management | No |
Ports & interfaces
| Specification | Value |
|---|---|
| Basic switching RJ-45 Ethernet ports quantity | 5 |
| Basic switching RJ-45 Ethernet ports type | 2.5G Ethernet (100/1000/2500) |
| Installed SFP modules quantity | 0 |
| Installed SFP+ modules quantity | 0 |
| Power connector | DC-in jack |
Network
| Specification | Value |
|---|---|
| Networking standards | IEEE 802.3az |
| 10G support | No |
| Flow control support | Yes |
Data transmission
| Specification | Value |
|---|---|
| MAC address table | 4000 entries |
| Switching capacity | 25 Gbit/s |
Security
| Specification | Value |
|---|---|
| IGMP snooping | Yes |
Design
| Specification | Value |
|---|---|
| Rack mounting | Yes |
| Stackable | No |
| Form factor | Desktop |
| Product colour | Black |
| Housing material | Metal |
Power
| Specification | Value |
|---|---|
| Power source | DC |
Power over Ethernet (PoE)
| Specification | Value |
|---|---|
| Power over Ethernet (PoE) | No |
