16-Port 10/100/1000 Rackmountable Switch
Model 16-Port 10/100/1000 Rackmountable SwitchPart no. DGS-1016D/BEAN 790069269981
41 specifications
- Speed1 Gbit/s
- Weight1.75 kg
- Switch typeUnmanaged
- Basic switching RJ-45 Ethernet ports quantity16
- Full duplexYes
- MAC address table8000 entries
Overview
- Speed
- 1 Gbit/s
- Weight
- 1.75 kg
- Switch type
- Unmanaged
- Basic switching RJ-45 Ethernet ports quantity
- 16
- Full duplex
- Yes
- MAC address table
- 8000 entries
- Brand
- D-Link
- Category
- Network Switch
- Model
- 16-Port 10/100/1000 Rackmountable Switch
- Part number
- DGS-1016D/B
- EAN / UPC
- 790069269981, 5052461532694, 5055851296060, 7900692699816
- Also known as
- D-Link 16-Port Gigabit Unmanaged Desktop Switch
Specifications
41 specifications in 13 groups
Management features
| Specification | Value |
|---|---|
| Switch type | Unmanaged |
Ports & interfaces
| Specification | Value |
|---|---|
| Basic switching RJ-45 Ethernet ports quantity | 16 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Network
| Specification | Value |
|---|---|
| Full duplex | Yes |
Data transmission
| Specification | Value |
|---|---|
| MAC address table | 8000 entries |
| Switching capacity | 32 Gbit/s |
| Store-and-forward | Yes |
| Maximum data transfer rate | 1 Gbit/s |
| Packet buffer memory | 0.340 MB |
Design
| Specification | Value |
|---|---|
| Number of fans | 0 fan(s) |
| Safety | CSA + NRTL/C |
Power
| Specification | Value |
|---|---|
| Power source | 100-240VAC, 50/60 Hz |
| Power supply included | Yes |
Power over Ethernet (PoE)
| Specification | Value |
|---|---|
| Power over Ethernet (PoE) | No |
Other features
| Specification | Value |
|---|---|
| Dimensions (WxDxH) | 280 x 180 x 44 mm |
| I/O ports | 10BASE-T, 100BASE-TX & 1000BASE-T |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -10 - 55 °C |
| Storage temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 5 - 95% |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 1.75 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 180 mm |
| Package depth | 328 mm |
| Package height | 108 mm |
| Package weight | 1.77 kg |
Technical details
| Specification | Value |
|---|---|
| Master (outer) cases per pallet (air) | 30 pc(s) |
| Master (outer) cases per pallet (sea) | 50 pc(s) |
| Pallet gross length | 110 cm |
| Pallet gross weight (air) | 304.5 kg |
| Pallet gross weight (sea) | 495 kg |
| Pallet gross width | 120 cm |
| Pallet height (air) | 121.2 cm |
| Pallet height (sea) | 193 cm |
| Products per pallet (air) | 150 pc(s) |
| Products per pallet (sea) | 250 pc(s) |
| Products per shipping (inner) case | 5 pc(s) |
| Shipping (inner) case gross weight | 9.5 kg |
| Shipping (inner) case height | 35.9 cm |
| Shipping (inner) case length | 57.2 cm |
| Shipping (inner) case net weight | 8.84 kg |
| Shipping (inner) case width | 19.7 cm |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85176990 |
