ASUS GigaX2124X Managed L2 Black
Model GigaX2124XPart no. 90-Q7R3AN2N0-3P3EAN 4719543909782
33 specifications
- Speed1 Gbit/s
- ConnectivityWired
- Weight3.5 kg
- ColourBlack
- Switch typeManaged
- Basic switching RJ-45 Ethernet ports quantity24
Overview
- Speed
- 1 Gbit/s
- Connectivity
- Wired
- Weight
- 3.5 kg
- Colour
- Black
- Switch type
- Managed
- Basic switching RJ-45 Ethernet ports quantity
- 24
- Brand
- ASUS
- Category
- Network Switch
- Model
- GigaX2124X
- Part numbers
- 90-Q7R3AN2N0-3P3, GX2124X, 90-Q7R3AN2N0B3EA1
- EAN / UPC
- 4719543909782, 610839911486, 4719543911488
- Also known as
- ASUS GigaX2124X Managed L2 Black
Specifications
33 specifications in 13 groups
Management features
| Specification | Value |
|---|---|
| Switch type | Managed |
| Switch layer | L2 |
| Quality of Service (QoS) support | Yes |
| Web-based management | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Basic switching RJ-45 Ethernet ports quantity | 24 |
| SFP module slots quantity | 4 |
| SFP/SFP+ slots quantity | 4 |
Network
| Specification | Value |
|---|---|
| Port mirroring | Yes |
| Full duplex | Yes |
| Flow control support | Yes |
| Link aggregation | Yes |
Data transmission
| Specification | Value |
|---|---|
| MAC address table | 4000 entries |
| Supported data transfer rates | 10/100/1000 Mbps |
| Switching capacity | 48 Gbit/s |
| Maximum data transfer rate | 1 Gbit/s |
Security
| Specification | Value |
|---|---|
| MAC address filtering | Yes |
Multicast features
| Specification | Value |
|---|---|
| Multicast support | Yes |
Protocols
| Specification | Value |
|---|---|
| Management protocols | SNMPv1,v2, v3 |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Safety | UL1950, TUV |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 50 W |
Power over Ethernet (PoE)
| Specification | Value |
|---|---|
| Power over Ethernet (PoE) | No |
Other features
| Specification | Value |
|---|---|
| Dimensions (WxDxH) | 442 x 325 x 44 mm |
| Connectivity technology | Wired |
| Packet transfer speed | 37.2 Mpps |
| Power requirements | AC, 100-240VAC, 50/60Hz |
| Wi-Fi | No |
| Connectivity LEDs | Yes |
| Electromagnetic emissions | FCC 15 A, CE Mark |
| Non-operating relative humidity (non-condensing) | 5 - 95% |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -25 - 70 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 3.5 kg |
