ASUS GigaX2024X Managed L2 Black
Model GigaX2024XPart no. 90-Q7I1AN2N03P1EAN 610839910212
33 specifications
- Speed1 Gbit/s
- ConnectivityWired
- ColourBlack
- Switch typeManaged
- Basic switching RJ-45 Ethernet ports quantity24
- Port mirroringYes
Overview
- Speed
- 1 Gbit/s
- Connectivity
- Wired
- Colour
- Black
- Switch type
- Managed
- Basic switching RJ-45 Ethernet ports quantity
- 24
- Port mirroring
- Yes
- Brand
- ASUS
- Category
- Network Switch
- Model
- GigaX2024X
- Part numbers
- 90-Q7I1AN2N03P1, 90-Q6P1AN2N0B3EB1, GX2024X
- EAN / UPC
- 610839910212, 4719543910214
- Also known as
- ASUS GigaX2024X Managed L2 Black
Specifications
33 specifications in 13 groups
Management features
| Specification | Value |
|---|---|
| Switch type | Managed |
| Switch layer | L2 |
| Quality of Service (QoS) support | Yes |
| Web-based management | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Basic switching RJ-45 Ethernet ports quantity | 24 |
| Gigabit Ethernet (copper) ports quantity | 2 |
Network
| Specification | Value |
|---|---|
| Port mirroring | Yes |
| Full duplex | Yes |
| IP routing | Yes |
| Broadcast storm control | Yes |
| Flow control support | Yes |
Data transmission
| Specification | Value |
|---|---|
| MAC address table | 8192 entries |
| Supported data transfer rates | 10/100/1000 Mbps |
| Switching capacity | 20 Gbit/s |
| Maximum data transfer rate | 1 Gbit/s |
Security
| Specification | Value |
|---|---|
| DHCP features | DHCP server, DHCP client |
| MAC address filtering | Yes |
Multicast features
| Specification | Value |
|---|---|
| Multicast support | Yes |
Protocols
| Specification | Value |
|---|---|
| Management protocols | SNMPv1/v2c/v3 |
Design
| Specification | Value |
|---|---|
| Stackable | No |
| Product colour | Black |
| Safety | UL1950, TUV, FCC 15A, CE Mark, CCC |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 50 W |
Power over Ethernet (PoE)
| Specification | Value |
|---|---|
| Power over Ethernet (PoE) | No |
Other features
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
| Authentication method | RADIUS |
| Power requirements | AC, 90-240VAC, 50/60Hz |
| Wi-Fi | No |
| Connectivity LEDs | Yes |
| Non-operating relative humidity (non-condensing) | 5 - 95% |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 70 °C |
Certificates
| Specification | Value |
|---|---|
| Certification | IEC 68-2-36, IEC 68-2-29, IEC 68-2-32 |
