GigaX 3112
Model GigaX 3112Part no. 90-Q611AN3N0B3EA1
18 specifications
- Speed1 Gbit/s
- Basic switching RJ-45 Ethernet ports quantity16
- Full duplexYes
- Switching capacity28 Gbit/s
- Management protocolsSNMP, Telnet, HTTP/HTTPS
- SafetyUL1950, TUV
Overview
- Speed
- 1 Gbit/s
- Basic switching RJ-45 Ethernet ports quantity
- 16
- Full duplex
- Yes
- Switching capacity
- 28 Gbit/s
- Management protocols
- SNMP, Telnet, HTTP/HTTPS
- Safety
- UL1950, TUV
- Brand
- ASUS
- Category
- Network Switch
- Model
- GigaX 3112
- Part numbers
- 90-Q611AN3N0B3EA1, 90-Q611AN3N0B3EA6
- Also known as
- ASUS GigaX 3112
Specifications
18 specifications in 8 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Basic switching RJ-45 Ethernet ports quantity | 16 |
Network
| Specification | Value |
|---|---|
| Networking standards | IEEE 802.1d, IEEE 802.1p, IEEE 802.1q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u |
| Full duplex | Yes |
Data transmission
| Specification | Value |
|---|---|
| Switching capacity | 28 Gbit/s |
| Maximum data transfer rate | 1 Gbit/s |
Protocols
| Specification | Value |
|---|---|
| Management protocols | SNMP, Telnet, HTTP/HTTPS |
| Data link protocols | Ethernet, Fast Ethernet, Gigabit Ethernet |
Design
| Specification | Value |
|---|---|
| Safety | UL1950, TUV |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 90 W |
Other features
| Specification | Value |
|---|---|
| Management platform | Web-based, CLI |
| Data transfer rate | 1000 Mbit/s |
| Dimensions (WxDxH) | 442 x 325 x 44 mm |
| Power requirements | AC 90-240V, 50/60 HZ |
| Electromagnetic emissions | FCC Part 15 Class A, CE Mark |
| I/O ports | 12 x 10/100/1000Base-TX ports 2 x SFP slots(1000Base-SX/-LX) 1 x USB port 1 x RS-232 port 1 x AC Power |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -25 - 70 °C |
| Storage relative humidity (H-H) | 5 - 95% |
