100) Power over Ethernet (PoE) 1U Grey

Model FS980M/52PSPart no. AT-FS980M/52PSEAN 767035209050

85 specifications

Overview

Brand: Allied Telesis
Category: Network Switch
Model: FS980M/52PS
Part numbers: AT-FS980M/52PS, AT-FS980M/52PS-30, AT-FS980M/52PS-10, ATFS980M52PS10
EAN / UPC: 767035209050, 767035209043
Also known as: Allied Telesis FS980M/52PS Managed L3 Fast Ethernet (10/100) Power over Ethernet (PoE) 1U Grey

85 specifications in 16 groups

Specification	Value
Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Web-based management	Yes
ARP inspection	Yes
Configuring Location Settings (CLI)	Yes
Traffic classification	Yes
System event log	Yes

Specification	Value
Basic switching RJ-45 Ethernet ports quantity	48
Basic switching RJ-45 Ethernet ports type	Fast Ethernet (10/100)
Fast Ethernet (copper) ports quantity	48
Installed SFP modules quantity	0
Installed SFP+ modules quantity	0
SFP module slots quantity	4
Fiber optic connector	SFP
Console port	RJ-45

Specification	Value
Networking standards	IEEE 802.1AX, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1v, IEEE 802.1w, IEEE 802.1x, IEEE 802.2, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ac, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3x, IEEE 802.3z
10G support	No
Copper ethernet cabling technology	10BASE-T, 100BASE-T
Port mirroring	Yes
Full duplex	Yes
Active link detection	Yes
Broadcast storm control	Yes
Flow control support	Yes
Link aggregation	Yes
Rate limiting	Yes
Spanning tree protocol	Yes
VLAN support	Yes
Virtual LAN features	Port-based VLAN, Private VLAN, Protocol-based VLAN, Tagged VLAN, Voice VLAN

Specification	Value
Fiber ethernet cabling technology	100BASE-X, 1000BASE-X

Specification	Value
DHCP features	DHCP client, DHCP snooping
Access Control List (ACL)	Yes
IGMP snooping	Yes
Authentication	MAC-based authentication, Web-based authentication
Authentication type	AAA, IEEE 802.1x, Network Access Control (NAC)
BPDU filtering/protection	Yes
Loop protection	Yes
Password protection	Yes
Queue scheduling algorithms	SP, WRR+SP, Weighted Round Robin (WRR)
SSH/SSL support	Yes
Security algorithms	3DES, AES, MD5, PEAP, SHA-1, SHA-2, SSH, SSL/TLS, TTLS
Static port security	Yes

Specification	Value
Multicast support	Yes

Specification	Value
Management protocols	SNMP, IGMPv1,IGMPv2,IGMPv3
Routing protocols	RIP-1, RIP-2

Specification	Value
Power over Ethernet (PoE)	Yes
Power over Ethernet (PoE) ports quantity	48
Total Power over Ethernet (PoE) budget	375 W

Specification	Value
Operating temperature (T-T)	0 - 50 °C
Storage temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	5 - 90%
Storage relative humidity (H-H)	5 - 95%
Operating altitude	0 - 3048 m
Heat dissipation	1800 BTU/h

Specification	Value
Package weight	8.2 kg

Specification	Value
Certification	FCC part15 B, EN55022 Class A, CISPR22:2006, VCCI Class A, C-Tick, EN 55024, UL 60950-1 Ed2, C22.2 NO.60950-1, EN 60950-1 Ed2, IEC60950-1 Ed.2, EN60950-1 Ed2, CE, cULus, TUV, RoHS
