Allied Telesis FS970M/16F8-SC Managed L3 Fast Ethernet (10/100) Grey

Allied Telesis FS970M/16F8-SC Managed L3 Fast Ethernet (10/100) Grey

Model FS970M/16F8-SCPart no. AT-FS970M/16F8-SC-50

58 specifications
  • Memory128 MB
  • Noise55.4 dB
  • Weight4.4 kg
  • ColourGrey
  • Switch typeManaged
  • Basic switching RJ-45 Ethernet ports quantity16
See all specifications

Overview

Memory
128 MB
Noise
55.4 dB
Weight
4.4 kg
Colour
Grey
Switch type
Managed
Basic switching RJ-45 Ethernet ports quantity
16
Brand
Allied Telesis
Model
FS970M/16F8-SC
Part number
AT-FS970M/16F8-SC-50
Also known as
Allied Telesis FS970M/16F8-SC Managed L3 Fast Ethernet (10/100) Grey

Specifications

58 specifications in 13 groups

Management features

Switch typeManaged
Switch layerL3
Quality of Service (QoS) supportYes
System event logYes
MIB supportYes

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity16
Basic switching RJ-45 Ethernet ports typeFast Ethernet (10/100)
Fast Ethernet (copper) ports quantity16
Gigabit Ethernet (copper) ports quantity2
Installed SFP modules quantity0
Installed SFP+ modules quantity0
Combo SFP ports quantity2
Fiber ports quantity8
Console portRJ-45

Network

Networking standardsIEEE 802.1D, IEEE 802.1Q, IEEE 802.1x, IEEE 802.2, IEEE 802.3, IEEE 802.3ac, IEEE 802.3af, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G supportNo
Copper ethernet cabling technology100BASE-FX
Port mirroringYes
Full duplexYes
Auto MDI/MDI-XYes
Broadcast storm controlYes
Flow control supportYes
Head-of-line (HOL) blockingYes
Link aggregationYes
VLAN supportYes
Virtual LAN featuresPrivate VLAN, Protocol-based VLAN, Port-based VLAN
Number of VLANs4096

Data transmission

MAC address table16000 entries
Switching capacity8.8 Gbit/s
Throughput6.5 Mpps

Security

DHCP featuresDHCP server, DHCP client
Access Control List (ACL)Yes
MAC address filteringYes

Multicast features

Multicast supportYes
Number of multicast groups filtered255

Design

Product colourGrey
SafetyUL 60950-1 (cUlus), EN60950-1 (TUV), EN60825

Performance

Processor frequency266 MHz
Memory typeRAM
Internal memory128 MB
Flash memory16 MB
Noise level55.4 dB

Power

AC input voltage100 - 240 V
AC input frequency47/63 Hz
Power consumption (max)22 W
Power plug typeType C

Power over Ethernet (PoE)

Power over Ethernet (PoE)No

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-25 - 70 °C
Operating relative humidity (H-H)5 - 90%
Storage relative humidity (H-H)5 - 95%
Operating altitude0 - 3048 m
Heat dissipation75 BTU/h

Weight & dimensions

Width441 mm
Depth323 mm
Height44 mm
Weight4.4 kg

Certificates

CertificationFCC class A, CISPR class A, EN55022 class A, C-TICK, VCCI Class A, CE, EN601000-3-2, EN601000-3-3
