Allied Telesis AT-X600-48TS/XP-60 Managed L3
Model AT-X600-48TS/XP-60Part no. 990-002630-60EAN 767035191003
44 specifications
- Memory512 MB
- Speed184 Gbit/s
- ConnectivityWired
- Noise46.8 dB
- Weight4.9 kg
- Switch typeManaged
Overview
- Memory
- 512 MB
- Speed
- 184 Gbit/s
- Connectivity
- Wired
- Noise
- 46.8 dB
- Weight
- 4.9 kg
- Switch type
- Managed
- Brand
- Allied Telesis
- Category
- Network Switch
- Model
- AT-X600-48TS/XP-60
- Part number
- 990-002630-60
- EAN / UPC
- 767035191003
- Also known as
- Allied Telesis AT-X600-48TS/XP-60 Managed L3
Specifications
44 specifications in 15 groups
Management features
| Specification | Value |
|---|---|
| Switch type | Managed |
| Switch layer | L3 |
| Quality of Service (QoS) support | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Basic switching RJ-45 Ethernet ports quantity | 44 |
| SFP module slots quantity | 4 |
| SFP/SFP+ slots quantity | 4 |
Network
| Specification | Value |
|---|---|
| Port mirroring | Yes |
| Full duplex | Yes |
| IP routing | Yes |
| Auto MDI/MDI-X | Yes |
| Link aggregation | Yes |
| Number of VLANs | 4000 |
Data transmission
| Specification | Value |
|---|---|
| MAC address table | 16000 entries |
| Supported data transfer rates | 10/100/1000 Mbps |
| Switching capacity | 48 Gbit/s |
| Maximum data transfer rate | 184 Gbit/s |
| Jumbo frames support | Yes |
Security
| Specification | Value |
|---|---|
| Access Control List (ACL) | Yes |
| MAC address filtering | Yes |
Protocols
| Specification | Value |
|---|---|
| Management protocols | SSH, RADIUS, RMON, LLDP-MED |
Design
| Specification | Value |
|---|---|
| Stackable | Yes |
Performance
| Specification | Value |
|---|---|
| Memory type | DDR-SDRAM |
| Internal memory | 512 MB |
| Flash memory | 64 MB |
| Noise level | 46.8 dB |
Power
| Specification | Value |
|---|---|
| Input voltage | 100 - 240 V |
| Power consumption (typical) | 112 W |
Power over Ethernet (PoE)
| Specification | Value |
|---|---|
| Power over Ethernet (PoE) | No |
Other features
| Specification | Value |
|---|---|
| Data transfer rate | 136.9 Mbit/s |
| Dimensions (WxDxH) | 440 x 408 x 44 mm |
| Connectivity technology | Wired |
| Authentication method | Dynamic VLAN, 802.1x, DHCP, BPDU, STP |
| Input frequency | 50/60 Hz |
| Networking features | 1000Mbps Ethernet |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -25 - 70 °C |
| Operating relative humidity (H-H) | 5 - 90% |
| Storage relative humidity (H-H) | 5 - 95% |
| Operating altitude | 0 - 3000 m |
| Operating temperature (T-T) | 32 - 104 °F |
| Heat dissipation | 382 BTU/h |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 4.9 kg |
Packaging data
| Specification | Value |
|---|---|
| Package weight | 6.5 kg |
Certificates
| Specification | Value |
|---|---|
| Certification | EN55022, FCC, VCCI, EN55024, EN61000, UL60950-1, CAN/CSA-C22.2, EN60950-1, EN60825-1, AS/NZS 60950.1, UL, cUL, TUV |
