Allied Telesis AT-x550-18XTQ-50 Managed L3
10G Ethernet (100/1000/10000) Grey
Model AT-x550-18XTQ-50Part no. 990-005105-50EAN 767035210131
43 specifications
- Memory1024 MB
- Noise50 dB
- ColourGrey
- Switch typeManaged
- Basic switching RJ-45 Ethernet ports quantity16
- Policy-based routingYes
Overview
- Memory
- 1024 MB
- Noise
- 50 dB
- Colour
- Grey
- Switch type
- Managed
- Basic switching RJ-45 Ethernet ports quantity
- 16
- Policy-based routing
- Yes
- Brand
- Allied Telesis
- Category
- Network Switch
- Model
- AT-x550-18XTQ-50
- Part number
- 990-005105-50
- EAN / UPC
- 767035210131, 767035220581
- Also known as
- Allied Telesis AT-x550-18XTQ-50 Managed L3 10G Ethernet (100/1000/10000) Grey
Specifications
43 specifications in 13 groups
Management features
| Specification | Value |
|---|---|
| Switch type | Managed |
| Switch layer | L3 |
| Quality of Service (QoS) support | Yes |
| Web-based management | Yes |
| ARP inspection | Yes |
| Traffic classification | Yes |
| Traffic shaping | Yes |
| System event log | Yes |
| MIB support | SNMP |
Ports & interfaces
| Specification | Value |
|---|---|
| Basic switching RJ-45 Ethernet ports quantity | 16 |
| Basic switching RJ-45 Ethernet ports type | 10G Ethernet (100/1000/10000) |
| Installed SFP modules quantity | 0 |
| Installed SFP+ modules quantity | 0 |
| Fiber ports quantity | 2 |
| Console port | RJ-45 |
| USB 2.0 ports quantity | 1 |
Network
| Specification | Value |
|---|---|
| Networking standards | IEEE 802.2, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3an, IEEE 802.3az, IEEE 802.3ba, IEEE 802.3x, IEEE 802.3z |
| Policy-based routing | Yes |
| Number of VLANs | 4094 |
Data transmission
| Specification | Value |
|---|---|
| MAC address table | 16000 entries |
| Switching capacity | 480 Gbit/s |
| Packet buffer memory | 4 MB |
Security
| Specification | Value |
|---|---|
| DHCP features | DHCP server, DHCPv6 relay, DHCPv6 server, DHCP client |
Multicast features
| Specification | Value |
|---|---|
| Multicast support | Yes |
Design
| Specification | Value |
|---|---|
| Rack mounting | Yes |
| Stackable | Yes |
| Product colour | Grey |
| LED indicators | Yes |
Performance
| Specification | Value |
|---|---|
| Memory type | DDR-SDRAM |
| Internal memory | 1024 MB |
| Flash memory | 1024 MB |
| Noise level | 50 dB |
Power
| Specification | Value |
|---|---|
| AC input voltage | 90 - 260 V |
| AC input frequency | 47/63 Hz |
| Power consumption (typical) | 128 W |
| Power plug type | Type C |
Power over Ethernet (PoE)
| Specification | Value |
|---|---|
| Power over Ethernet (PoE) | No |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 45 °C |
| Heat dissipation | 436 BTU/h |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 210 mm |
| Depth | 346 mm |
| Height | 42.5 mm |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85176990 |
