Allied Telesis AT-X550-18XTQ-30 network switch Managed L3
10G Ethernet (100/1000/10000) Grey
Model AT-X550-18XTQ-30EAN 767035210117
50 specifications
- Memory1024 MB
- Noise50 dB
- ColourGrey
- Switch typeManaged
- Basic switching RJ-45 Ethernet ports quantity16
- Networking standardsIEEE 802.2, IEEE 802.3
Overview
- Memory
- 1024 MB
- Noise
- 50 dB
- Colour
- Grey
- Switch type
- Managed
- Basic switching RJ-45 Ethernet ports quantity
- 16
- Networking standards
- IEEE 802.2, IEEE 802.3
- Brand
- Allied Telesis
- Category
- Network Switch
- Model
- AT-X550-18XTQ-30
- Part number
- AT-X550-18XTQ-30
- EAN / UPC
- 767035210117
- Also known as
- Allied Telesis AT-X550-18XTQ-30 network switch Managed L3 10G Ethernet (100/1000/10000) Grey
Specifications
50 specifications in 13 groups
Management features
| Specification | Value |
|---|---|
| Switch type | Managed |
| Switch layer | L3 |
| Quality of Service (QoS) support | Yes |
| Web-based management | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Basic switching RJ-45 Ethernet ports quantity | 16 |
| Basic switching RJ-45 Ethernet ports type | 10G Ethernet (100/1000/10000) |
| Installed QSFP+ modules quantity | 2 |
Network
| Specification | Value |
|---|---|
| Networking standards | IEEE 802.2, IEEE 802.3 |
| 10G support | Yes |
| Port mirroring | Yes |
| Full duplex | Yes |
| IP routing | Yes |
| Flow control support | Yes |
| Spanning tree protocol | Yes |
| VLAN support | Yes |
| Number of VLANs | 4094 |
Data transmission
| Specification | Value |
|---|---|
| MAC address table | 16000 entries |
| Switching capacity | 480 Gbit/s |
| Latency (1 Gbps) | 3.9 µs |
| Latency (10 Gbps) | 3 µs |
| Jumbo frames support | Yes |
| Packet buffer memory | 4 MB |
Security
| Specification | Value |
|---|---|
| DHCP features | DHCP server, DHCP client |
| Access Control List (ACL) | Yes |
| IGMP snooping | Yes |
| BPDU filtering/protection | Yes |
| Loop protection | Yes |
| MAC address filtering | Yes |
| SSH/SSL support | Yes |
Multicast features
| Specification | Value |
|---|---|
| Multicast support | Yes |
Design
| Specification | Value |
|---|---|
| Rack mounting | Yes |
| Stackable | Yes |
| Product colour | Grey |
Performance
| Specification | Value |
|---|---|
| Internal memory | 1024 MB |
| Flash memory | 1024 MB |
| Noise level | 50 dB |
Power
| Specification | Value |
|---|---|
| AC input voltage | 90 - 260 V |
| AC input frequency | 47/63 Hz |
| Power consumption (max) | 128 W |
Power over Ethernet (PoE)
| Specification | Value |
|---|---|
| Power over Ethernet (PoE) | No |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 45 °C |
| Storage temperature (T-T) | -25 - 70 °C |
| Operating relative humidity (H-H) | 5 - 90% |
| Storage relative humidity (H-H) | 5 - 95% |
| Operating altitude | 0 - 3048 m |
| Heat dissipation | 436 BTU/h |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 210 mm |
| Depth | 346 mm |
| Height | 42.5 mm |
Logistics data
| Specification | Value |
|---|---|
| Country of origin | China |
