Allied Telesis AT-x230-10GP-50 Managed L2+ Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Grey

Allied Telesis AT-x230-10GP-50 Managed L2+ Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Grey

Model AT-x230-10GP-50Part no. 990-004031-50EAN 767035202020

43 specifications
  • Weight2.1 kg
  • ColourGrey
  • Switch typeManaged
  • Basic switching RJ-45 Ethernet ports quantity8
  • 10G supportNo
  • Switching capacity20 Gbit/s
See all specifications

Overview

Weight
2.1 kg
Colour
Grey
Switch type
Managed
Basic switching RJ-45 Ethernet ports quantity
8
10G support
No
Switching capacity
20 Gbit/s
Brand
Allied Telesis
Model
AT-x230-10GP-50
Part number
990-004031-50
EAN / UPC
767035202020, 767035223155
Also known as
Allied Telesis AT-x230-10GP-50 Managed L2+ Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Grey

Specifications

43 specifications in 14 groups

Management features

Switch typeManaged
Switch layerL2+
Quality of Service (QoS) supportYes
Web-based managementYes
System event logYes

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity8
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
SFP module slots quantity2
Console portRJ-45
Power connectorDC-in jack

Network

Networking standardsIEEE 802.2, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G supportNo
Port mirroringYes
Auto MDI/MDI-XYes
Broadcast storm controlYes
VLAN supportYes
Number of VLANs2048

Data transmission

Switching capacity20 Gbit/s
Throughput14.9 Mpps
Jumbo frames supportYes
Packet buffer memory1.5 MB

Security

DHCP featuresDHCPv6 client, DHCP client
SSH/SSL supportYes

Multicast features

Multicast supportYes

Design

Rack mountingNo
Product colourGrey
LED indicatorsYes
SafetyUL60950-1, CAN/CSA-C22.2 No. 60950-1-03, EN60950-1, EN60825-1, AS/NZS 60950.1

Performance

Flash memory64 MB

Power

Power consumption (typical)16 W

Power over Ethernet (PoE)

Power over Ethernet (PoE)Yes
Power over Ethernet (PoE) ports quantity8

Operational conditions

Operating temperature (T-T)0 - 50 °C
Storage temperature (T-T)-20 - 70 °C
Operating relative humidity (H-H)5 - 90%
Storage relative humidity (H-H)5 - 95%
Heat dissipation126 BTU/h

Weight & dimensions

Width210 mm
Depth275 mm
Height42.5 mm
Weight2.1 kg

Certificates

CertificationUL, cUL, UL-EU

Logistics data

Harmonized System (HS) code85176990
