Allied Telesis AT-x210-24GT-50 Managed L2+ Gigabit Ethernet (10/100/1000) 1U Grey

Allied Telesis AT-x210-24GT-50 Managed L2+ Gigabit Ethernet (10/100/1000) 1U Grey

Model AT-x210-24GT-50Part no. 990-003857-50EAN 767035199771

57 specifications
  • Memory256 MB
  • Type1U
  • Weight2.7 kg
  • ColourGrey
  • Switch typeManaged
  • Basic switching RJ-45 Ethernet ports quantity24
See all specifications

Overview

Memory
256 MB
Type
1U
Weight
2.7 kg
Colour
Grey
Switch type
Managed
Basic switching RJ-45 Ethernet ports quantity
24
Brand
Allied Telesis
Model
AT-x210-24GT-50
Part number
990-003857-50
EAN / UPC
767035199771, 767035199818, 5706998250872
Also known as
Allied Telesis AT-x210-24GT-50 Managed L2+ Gigabit Ethernet (10/100/1000) 1U Grey

Specifications

57 specifications in 14 groups

Management features

Switch typeManaged
Switch layerL2+
Quality of Service (QoS) supportYes
Web-based managementYes
System event logYes
MIB supportRFC1212, RFC1213, RFC1227, RFC1239, RFC2011, RFC2012, RFC2013, RFC2096, RFC2819, RFC2863, RFC3418, RFC3636

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity24
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity20
Combo SFP ports quantity4
Power connectorDC-in jack

Network

Networking standardsIEEE 802.2, IEEE 802.3, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G supportNo
Port mirroringYes
Full duplexYes
IP routingYes
Auto MDI/MDI-XYes
Broadcast storm controlYes
Flow control supportYes
Link aggregationYes
Spanning tree protocolYes
VLAN supportYes
Number of VLANs256

Data transmission

MAC address table8000 entries
Switching capacity48 Gbit/s
Throughput35.7 Mpps
Latency (1 Gbps)4.1 µs
Number of queues4
Jumbo frames supportYes
Packet buffer memory0.512 MB

Security

DHCP featuresDHCP server, DHCP client
IGMP snoopingYes
Security algorithmsMD5, PEAP, SSH, SSL/TLS

Multicast features

Multicast supportYes

Protocols

Management protocolsSNMP, Telnet, NTP
Supported network protocolsICMP, ARP, SMTP

Design

Rack mountingYes
Form factor1U
Product colourGrey
LED indicatorsYes
SafetyUL60950-1, CAN/CSA-C22.2, 60950-1-03, EN60950-1, EN60825-1, AS/NZS 60950.1

Performance

Internal memory256 MB
Flash memory64 MB

Power

Power consumption (typical)25 W
Power consumption (max)28 W

Power over Ethernet (PoE)

Power over Ethernet (PoE)No

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-25 - 70 °C
Operating relative humidity (H-H)5 - 90%
Storage relative humidity (H-H)5 - 95%
Operating altitude0 - 3048 m
Heat dissipation94.8 BTU/h

Weight & dimensions

Width440 mm
Depth210 mm
Height44 mm
Weight2.7 kg

Certificates

CertificationUL, cUL, UL-EU
