Allied Telesis AT-IS230-10GP-80 Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black

Allied Telesis AT-IS230-10GP-80 Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black

Model AT-IS230-10GP-80Part no. 990-006028-80EAN 767035215259

66 specifications

Weight1.2 kg
ColourBlack
Switch typeManaged
Basic switching RJ-45 Ethernet ports quantity8
10G supportNo
Fiber ethernet cabling technology100BASE-X, 1000BASE-X

See all specifications

Overview

Weight: 1.2 kg
Colour: Black
Switch type: Managed
Basic switching RJ-45 Ethernet ports quantity: 8
10G support: No
Fiber ethernet cabling technology: 100BASE-X, 1000BASE-X

Brand: Allied Telesis
Category: Network Switch
Model: AT-IS230-10GP-80
Part number: 990-006028-80
EAN / UPC: 767035215259
Also known as: Allied Telesis AT-IS230-10GP-80 Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black

Specifications

66 specifications in 16 groups

Management features

Specification	Value
Switch type	Managed
Switch layer	L2
Quality of Service (QoS) support	Yes
MIB support	RFC 1212, RFC 1213, RFC 1239, RFC 2819, RFC 2863, RFC 3418, RFC 4022, RFC 4113

Ports & interfaces

Specification	Value
Basic switching RJ-45 Ethernet ports quantity	8
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Installed SFP modules quantity	0
Installed SFP+ modules quantity	0
Combo SFP ports quantity	2
Fiber optic connector	SFP

Network

Specification	Value
Networking standards	IEEE 802.1AX, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1ad, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.2, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ac, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G support	No
Copper ethernet cabling technology	1000BASE-T
Port mirroring	Yes
Full duplex	Yes
Flow control support	Yes
Link aggregation	Yes
Spanning tree protocol	Yes
VLAN support	Yes
Virtual LAN features	Multicast VLAN, Stacked VLAN, Tagged VLAN
Number of VLANs	4094

Optical fiber

Specification	Value
Fiber ethernet cabling technology	100BASE-X, 1000BASE-X

Data transmission

Specification	Value
MAC address table	8000 entries
Switching capacity	20 Gbit/s
Forwarding rate	14.88 Mpps
Number of queues	8
Jumbo frames support	Yes
Jumbo frames	9000
Packet buffer memory	4 MB

Security

Specification	Value
DHCP features	DHCP relay
IGMP snooping	Yes
Authentication	Port-based authentication
Loop protection	Yes
SSH/SSL support	Yes
Security algorithms	3DES, 802.1x RADIUS, DES, RSA, SHA-1, SNMP, SNMPv3, SSH, SSH-2, SSL/TLS

Multicast features

Specification	Value
Multicast support	Yes

Protocols

Specification	Value
GARP VLAN Registration Protocol (GVRP)	Yes

Design

Specification	Value
Rack mounting	No
Product colour	Black
Housing material	Metal
LED indicators	Yes
DIN rail mounting	Yes
International Protection (IP) code	IP30
Wall mountable	Yes
Safety	CSA C22.2 No. 61010-2-201, IEC60950-1, UL60950-1, UL61010-2-201
Electromagnetic compatibility	AS/NZS CISPR 32, A; EN55024; EN55032, A; EN61000-6-2; EN61000-6-4, A; FCC 15B, A; ICES-003, 6, A; VCCI, A

Performance

Specification	Value
Buffer size	512 KB

Power

Specification	Value
DC input voltage	24 - 48 V
Power consumption (max)	139.3 W

Power over Ethernet (PoE)

Specification	Value
Power over Ethernet (PoE)	Yes
Power over Ethernet (PoE) ports quantity	8
Power over Ethernet plus (PoE+) ports quantity	4
Power over Ethernet (PoE) power per port	30 W
Total Power over Ethernet (PoE) budget	120 W

Operational conditions

Specification	Value
Operating temperature (T-T)	-40 - 75 °C
Storage temperature (T-T)	-40 - 85 °C
Operating relative humidity (H-H)	10 - 95%
Storage relative humidity (H-H)	10 - 95%
Operating altitude	0 - 3000 m
Heat dissipation	475.3 BTU/h

Weight & dimensions

Specification	Value
Width	74 mm
Depth	105 mm
Height	152 mm
Weight	1.2 kg

Certificates

Specification	Value
Certification	CE, FCC, RCM, TUV, VCCI, RoHS, WEEE

Logistics data

Specification	Value
Harmonized System (HS) code	85176990
