Allied Telesis AT-IE210L-18GP-60 Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Grey

Allied Telesis AT-IE210L-18GP-60 Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Grey

Model AT-IE210L-18GP-60Part no. 990-005966-60EAN 767035214474

86 specifications
  • Memory512 MB
  • Noise33 dB
  • Weight3 kg
  • ColourGrey
  • Switch typeManaged
  • Basic switching RJ-45 Ethernet ports quantity16
See all specifications

Overview

Memory
512 MB
Noise
33 dB
Weight
3 kg
Colour
Grey
Switch type
Managed
Basic switching RJ-45 Ethernet ports quantity
16
Brand
Allied Telesis
Model
AT-IE210L-18GP-60
Part number
990-005966-60
EAN / UPC
767035214474
Also known as
Allied Telesis AT-IE210L-18GP-60 Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Grey

Specifications

86 specifications in 15 groups

Management features

Switch typeManaged
Switch layerL2
Quality of Service (QoS) supportYes
Web-based managementYes
ARP inspectionYes
Configuring Location Settings (CLI)Yes
Traffic classificationYes
System event logYes
MIB supportComprehensive SNMP

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity16
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity16
Installed SFP+ modules quantity0
SFP module slots quantity2
Power connectorAC-in jack

Network

Networking standardsIEEE 802.1Q, IEEE 802.1ad, IEEE 802.1v, IEEE 802.2, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G supportNo
Copper ethernet cabling technology10BASE-T, 100BASE-FX, 100BASE-T, 1000BASE-LX, 1000BASE-SX, 1000BASE-T
Port mirroringYes
Full duplexYes
Policy-based routingYes
Flow control supportYes
Link aggregationYes
Spanning tree protocolYes
VLAN supportYes
Virtual LAN featuresPolicy-based VLAN, VLAN Identifier ( VLAN ID)
Number of VLANs2048

Data transmission

MAC address table16000 entries
Switching capacity36 Gbit/s
Forwarding rate26.8 Mpps
Latency (10-100 Mbps)56 µs
Latency (1 Gbps)7.9 µs
Latency (10 Gbps)3.4 µs
Number of queues8
Static routeYes
Jumbo frames supportYes
Jumbo frames10000

Security

DHCP featuresDHCP client, DHCP relay, DHCP server, DHCP snooping, DHCPv6 client, DHCPv6 relay
Access Control List (ACL)Yes
IGMP snoopingYes
AuthenticationMAC-based authentication, Port-based authentication, Web-based authentication
Authentication typeIEEE 802.1x, Network Access Control (NAC), RADIUS
BPDU filtering/protectionYes
Loop protectionYes
MAC address entriesBlackhole MAC address entries
MAC address filteringYes
SSH/SSL supportYes
Security algorithms802.1x RADIUS, HTTPS, MD5, PEAP, SSH, SSH-2, SSL/TLS, TTLS

Multicast features

Multicast supportYes
Multicast MAC address table512 entries
Multicast Listener Discovery (MLD) snoopingMLDv1 and v2

Design

Rack mountingYes
StackableYes
Product colourGrey
LED indicatorsYes
Electromagnetic compatibilityEN55032 class A, FCC class A, VCCI class A, ICES-003 class A, EN55024, EN61000-3-2 (harmonic), EN61000-3-3 (flicker)

Performance

Memory typeDDR3-SDRAM
Internal memory512 MB
Flash memory128 MB
Noise level33 dB

Power

Power supply includedYes
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Input current4.2 A
Power consumption (max)21 W

Power over Ethernet (PoE)

Power over Ethernet (PoE)Yes
Power over Ethernet (PoE) ports quantity16
Power over Ethernet plus (PoE+) ports quantity8
Power over Ethernet (PoE) power per port15 W
Total Power over Ethernet (PoE) budget247 W

Operational conditions

Operating temperature (T-T)0 - 65 °C
Storage temperature (T-T)-30 - 70 °C
Operating relative humidity (H-H)5 - 95%
Storage relative humidity (H-H)5 - 95%
Operating altitude0 - 3048 m
Heat dissipation169 BTU/h

Weight & dimensions

Width341 mm
Depth231 mm
Height44 mm
Weight3 kg

Packaging data

Package width430 mm
Package depth360 mm
Package height150 mm
Package weight4.35 kg

Certificates

CertificationUL, cUL, UL60950-1, CAN/CSA-C22.2 No. 60950-1-03, EN60950-1, EN60825-1, AS/NZS 60950.1

Logistics data

Harmonized System (HS) code85176990
