Allied Telesis AT-GS970M/18-30 network switch Managed L3 Gigabit Ethernet (10/100/1000) 1U Grey

Allied Telesis AT-GS970M/18-30 network switch Managed L3 Gigabit Ethernet (10/100/1000) 1U Grey

Model AT-GS970M/18-30EAN 767035211404

90 specifications

Memory512 MB
Noise29 dB
Type1U
Weight2.4 kg
ColourGrey
Switch typeManaged

See all specifications

Overview

Memory: 512 MB
Noise: 29 dB
Type: 1U
Weight: 2.4 kg
Colour: Grey
Switch type: Managed

Brand: Allied Telesis
Category: Network Switch
Model: AT-GS970M/18-30
Part number: AT-GS970M/18-30
EAN / UPC: 767035211404, 7670352114040
Also known as: Allied Telesis AT-GS970M/18-30 network switch Managed L3 Gigabit Ethernet (10/100/1000) 1U Grey

Specifications

90 specifications in 17 groups

Management features

Specification	Value
Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Web-based management	Yes
ARP inspection	Yes
Traffic classification	Yes
System event log	Yes
MIB support	SNMP MIB

Ports & interfaces

Specification	Value
Basic switching RJ-45 Ethernet ports quantity	16
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity	16
Installed SFP modules quantity	0
Installed SFP+ modules quantity	0
Combo SFP ports quantity	2
Fiber optic connector	SFP
Console port	RS-232
Compatible memory cards	SD, SDHC

Network

Specification	Value
Networking standards	IEEE 802.2, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G support	No
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Port mirroring	Yes
Full duplex	Yes
Broadcast storm control	Yes
Ethernet Ring Protection Switching (ERPS)	Yes
Fast leave	Yes
Flow control support	Yes
Link aggregation	Yes
Spanning tree protocol	Yes
VLAN support	Yes
Virtual LAN features	Private VLAN, Voice VLAN, Tagged VLAN, Protocol-based VLAN, Port-based VLAN
Number of VLANs	4094

Optical fiber

Specification	Value
Fiber ethernet cabling technology	100BASE-X, 1000BASE-X

Data transmission

Specification	Value
MAC address table	16000 entries
Switching capacity	36 Gbit/s
Forwarding rate	26.8 Mpps
Latency (10-100 Mbps)	7.9 µs
Latency (1 Gbps)	3.4 µs
Static route	Yes
Jumbo frames support	Yes
Jumbo frames	10000
Packet buffer memory	1.5 MB

Security

Specification	Value
DHCP features	DHCP snooping, DHCP client
Access Control List (ACL)	Yes
IGMP snooping	Yes
Authentication	MAC-based authentication, Port-based authentication, Web-based authentication
Authentication type	AAA, IEEE 802.1x, Network Access Control (NAC), RADIUS
BPDU filtering/protection	Yes
Loop protection	Yes
MAC address filtering	Yes
Neighbor discovery snooping	Yes
Password protection	Yes
Root protection	Yes
SSH/SSL support	Yes
Security algorithms	3DES, AES, MD5, PEAP, RSA, SHA-1, SHA-2, SSH, SSH-2, SSL/TLS, TTLS

Multicast features

Specification	Value
Multicast support	Yes

Protocols

Specification	Value
Routing protocols	RIP, RIP-2

Design

Specification	Value
Rack mounting	Yes
Form factor	1U
Product colour	Grey
LED indicators	Yes
Wall mountable	Yes
Safety	EN60950-1 (TUV), UL 60950- 1(cULus), EN60825-1

Performance

Specification	Value
Memory type	DDR-SDRAM
Internal memory	512 MB
Flash memory	64 MB
Noise level	29 dB
Telnet	Yes

Power

Specification	Value
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Input current	2.4 A
Power consumption (max)	18 W

Power over Ethernet (PoE)

Specification	Value
Power over Ethernet (PoE)	No

Operational conditions

Specification	Value
Operating temperature (T-T)	0 - 50 °C
Storage temperature (T-T)	-25 - 70 °C
Operating relative humidity (H-H)	5 - 90%
Storage relative humidity (H-H)	5 - 95%
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 4000 m
Heat dissipation	61 BTU/h

Weight & dimensions

Specification	Value
Width	341 mm
Depth	231 mm
Height	44 mm
Weight	2.4 kg

Packaging data

Specification	Value
Included power plug types	UK
Package width	430 mm
Package depth	360 mm
Package height	150 mm
Package weight	4 kg

Certificates

Specification	Value
Certification	FCC Class A, EN55022 Class A, EN61000-3-2, EN61000-3-3, VCCI Class A, CISPR Class A

Logistics data

Specification	Value
Country of origin	China
