Allied Telesis AT-GS950/16 Managed

Allied Telesis AT-GS950/16 Managed

Model AT-GS950/16Part no. AT-GS950/16-10EAN 767035178387

28 specifications
  • Memory8 MB
  • Speed1 Gbit/s
  • Weight2.38 kg
  • Switch typeManaged
  • Basic switching RJ-45 Ethernet ports quantity16
  • Port mirroringYes
See all specifications

Overview

Memory
8 MB
Speed
1 Gbit/s
Weight
2.38 kg
Switch type
Managed
Basic switching RJ-45 Ethernet ports quantity
16
Port mirroring
Yes
Brand
Allied Telesis
Model
AT-GS950/16
Part numbers
AT-GS950/16-10, AT-GS950/16-30
EAN / UPC
767035178387, 767035178400, 7670351784008, 7670351783872
Also known as
Allied Telesis AT-GS950/16 Managed

Specifications

28 specifications in 11 groups

Management features

Switch typeManaged
Quality of Service (QoS) supportYes
Web-based managementYes

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity16
Combo SFP ports quantity2
SFP/SFP+ slots quantity2

Network

Networking standardsIEEE 802.1D, IEEE 802.1s, IEEE 802.1W, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Port mirroringYes
Flow control supportYes
Link aggregationYes

Data transmission

MAC address table8000 entries
Supported data transfer rates10/100/1000 Mbps
Maximum data transfer rate1 Gbit/s
Packet buffer memory0.5 MB

Design

StackableNo

Performance

Internal memory8 MB
Flash memory2 MB

Power over Ethernet (PoE)

Power over Ethernet (PoE)No

Other features

Dimensions (WxDxH)352 x 256 x 43.2 mm
Networking featuresGigabit Ethernet
Packet transfer speed1488000 pps
Power requirements100-240V AC, 50/60Hz
Non-operating relative humidity (non-condensing)5 - 95%

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-25 - 70 °C
Operating relative humidity (H-H)5 - 90%

Weight & dimensions

Weight2.38 kg

Certificates

CertificationUL 1950 FCC/EN55022 Class A VCCI Class A C-Tick EN60950 (TUV) EN55024 CE
