Allied Telesis AT-GS910/24-30 network switch Unmanaged Gigabit Ethernet (10/100/1000) 1U Grey

Allied Telesis AT-GS910/24-30 network switch Unmanaged Gigabit Ethernet (10/100/1000) 1U Grey

Model AT-GS910/24-30EAN 767035207520

48 specifications
  • Type1U
  • Weight2.1 kg
  • ColourGrey
  • Switch typeUnmanaged
  • Basic switching RJ-45 Ethernet ports quantity24
  • 10G supportNo
See all specifications

Overview

Type
1U
Weight
2.1 kg
Colour
Grey
Switch type
Unmanaged
Basic switching RJ-45 Ethernet ports quantity
24
10G support
No
Brand
Allied Telesis
Model
AT-GS910/24-30
Part number
AT-GS910/24-30
EAN / UPC
767035207520
Also known as
Allied Telesis AT-GS910/24-30 network switch Unmanaged Gigabit Ethernet (10/100/1000) 1U Grey

Specifications

48 specifications in 13 groups

Management features

Switch typeUnmanaged
Web-based managementYes

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity24
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity24
Installed SFP modules quantity0
Installed SFP+ modules quantity0
Console portRJ-45

Network

Networking standardsIEEE 802.3, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
10G supportNo
Copper ethernet cabling technology10BASE-T, 100BASE-T, 1000BASE-T
Full duplexYes
Auto-negotiationYes
Broadcast storm controlYes
Flow control supportYes

Data transmission

MAC address table8000 entries
Switching capacity48 Gbit/s
Throughput35.7 Mpps
Jumbo frames supportYes
Jumbo frames10000
Packet forwarding rate (1 Gbps)1488000 pps
Packet forwarding rate (10 Mbps)14880 pps
Packet forwarding rate (100 Mbps)148800 pps

Security

BPDU filtering/protectionYes
Loop protectionYes

Design

Rack mountingYes
Form factor1U
Product colourGrey
Housing materialMetal
LED indicatorsYes
Wall mountableYes
SafetyUL60950-1, 2nd Edition, CSA C22.2 No.60950-1-07, 2nd Edition, IEC60950-1(UL-EU, UL-CB)

Performance

Buffer size524 KB

Power

AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Input current0.4 A
Power consumption (max)17 W

Power over Ethernet (PoE)

Power over Ethernet (PoE)No

Operational conditions

Operating temperature (T-T)0 - 50 °C
Storage temperature (T-T)-25 - 70 °C
Operating relative humidity (H-H)5 - 90%
Storage relative humidity (H-H)5 - 95%

Weight & dimensions

Width341 mm
Depth210 mm
Height44 mm
Weight2.1 kg

Packaging data

Included power plug typesUK

Certificates

CertificationEAC certification, EN55024, ICES Class A, VCCI Class A, FCC Class A, RCM, CE, EN55022, CISPR 55022
