Allied Telesis AT-FS750/28-50 Managed Fast Ethernet (10/100) 1U Grey

Allied Telesis AT-FS750/28-50 Managed Fast Ethernet (10/100) 1U Grey

Model AT-FS750/28-50Part no. 990-004644-50EAN 767035203942

50 specifications
  • Type1U
  • Weight2.2 kg
  • ColourGrey
  • Switch typeManaged
  • Basic switching RJ-45 Ethernet ports quantity28
  • 10G supportNo
See all specifications

Overview

Type
1U
Weight
2.2 kg
Colour
Grey
Switch type
Managed
Basic switching RJ-45 Ethernet ports quantity
28
10G support
No
Brand
Allied Telesis
Model
AT-FS750/28-50
Part number
990-004644-50
EAN / UPC
767035203942
Also known as
Allied Telesis AT-FS750/28-50 Managed Fast Ethernet (10/100) 1U Grey

Specifications

50 specifications in 13 groups

Management features

Switch typeManaged
Quality of Service (QoS) supportYes
Web-based managementYes
System event logYes
MIB supportRFC 1213 MIB-II, RFC 1643 Ethernet MIB, RFC 1493 Bridge MIB, RFC 2131 DHCP client, Private Enterprise MIB

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity28
Basic switching RJ-45 Ethernet ports typeFast Ethernet (10/100)
Fast Ethernet (copper) ports quantity24
Gigabit Ethernet (copper) ports quantity2
Installed SFP modules quantity0
Installed SFP+ modules quantity0
Combo SFP ports quantity2

Network

Networking standardsIEEE 802.11d, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G supportNo
Port mirroringYes
Broadcast storm controlYes
Flow control supportYes
Head-of-line (HOL) blockingYes
Link aggregationYes
Rate limitingYes
Spanning tree protocolYes
Virtual LAN featuresTagged VLAN, Port-based VLAN

Data transmission

MAC address table8000 entries
Switching capacity12.8 Gbit/s
Number of queues4
Jumbo frames supportYes
Packet forwarding rate (1 Gbps)1488000 pps
Packet forwarding rate (10 Mbps)14880 pps
Packet forwarding rate (100 Mbps)148800 pps

Security

DHCP featuresDHCP client
Access Control List (ACL)Yes
IGMP snoopingYes
AuthenticationMAC-based authentication
MAC address filteringYes

Multicast features

Multicast supportYes
Number of multicast groups filtered256

Design

Rack mountingYes
Form factor1U
Product colourGrey

Power

AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power consumption (max)8.7 W

Power over Ethernet (PoE)

Power over Ethernet (PoE)No

Operational conditions

Operating temperature (T-T)0 - 40 °C

Weight & dimensions

Width330 mm
Depth18 mm
Height44 mm
Weight2.2 kg

Packaging content

Cables includedAC

Logistics data

Harmonized System (HS) code85176990
