Allied Telesis AT-FS705LE-50 Unmanaged
Model AT-FS705LE-50Part no. 990-002618-50EAN 767035134789
22 specifications
- Speed1 Gbit/s
- ConnectivityWired
- Weight224 g
- Switch typeUnmanaged
- Basic switching RJ-45 Ethernet ports quantity5
- 10G supportNo
Overview
- Speed
- 1 Gbit/s
- Connectivity
- Wired
- Weight
- 224 g
- Switch type
- Unmanaged
- Basic switching RJ-45 Ethernet ports quantity
- 5
- 10G support
- No
- Brand
- Allied Telesis
- Category
- Network Switch
- Model
- AT-FS705LE-50
- Part number
- 990-002618-50
- EAN / UPC
- 767035134789
- Also known as
- Allied Telesis AT-FS705LE-50 Unmanaged
Specifications
22 specifications in 11 groups
Management features
| Specification | Value |
|---|---|
| Switch type | Unmanaged |
Ports & interfaces
| Specification | Value |
|---|---|
| Basic switching RJ-45 Ethernet ports quantity | 5 |
Network
| Specification | Value |
|---|---|
| 10G support | No |
| Full duplex | Yes |
| Auto MDI/MDI-X | Yes |
Data transmission
| Specification | Value |
|---|---|
| MAC address table | 2000 entries |
| Supported data transfer rates | 10/100/1000 Mbps |
| Maximum data transfer rate | 1 Gbit/s |
Design
| Specification | Value |
|---|---|
| Stackable | No |
Power
| Specification | Value |
|---|---|
| Input current | 1 A |
| Input voltage | 7.5 V |
Power over Ethernet (PoE)
| Specification | Value |
|---|---|
| Power over Ethernet (PoE) | No |
Other features
| Specification | Value |
|---|---|
| Data transfer rate | 0.7 Mbit/s |
| Dimensions (WxDxH) | 116 x 70 x 25 mm |
| Connectivity technology | Wired |
| Input frequency | 50/60 Hz |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -25 - 70 °C |
| Operating relative humidity (H-H) | 5 - 80% |
| Storage relative humidity (H-H) | 5 - 95% |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 224 g |
Certificates
| Specification | Value |
|---|---|
| Certification | UL 1950, CSA 22.2 No. 950, FCC/EN55022 Class B, VCCI Class B, EN60950 (TUV), EN55024, CE |
