Allied Telesis AT-8100S/24POE Managed L3+ Gigabit Ethernet (10/100/1000) 1U Grey

Allied Telesis AT-8100S/24POE Managed L3+ Gigabit Ethernet (10/100/1000) 1U Grey

Model AT-8100S/24POEPart no. AT-8100S/24POE-10EAN 7670351949360

43 specifications
  • Type1U
  • Weight2.2 kg
  • ColourGrey
  • Switch typeManaged
  • Basic switching RJ-45 Ethernet ports quantity24
  • 10G supportNo
See all specifications

Overview

Type
1U
Weight
2.2 kg
Colour
Grey
Switch type
Managed
Basic switching RJ-45 Ethernet ports quantity
24
10G support
No
Brand
Allied Telesis
Model
AT-8100S/24POE
Part numbers
AT-8100S/24POE-10, AT-8100S/24POE-50, AT-8100S/24POE-30
EAN / UPC
7670351949360, 767035194974, 7670351949742, 767035194950 +1 more
Also known as
Allied Telesis AT-8100S/24POE Managed L3+ Gigabit Ethernet (10/100/1000) 1U Grey

Specifications

43 specifications in 11 groups

Management features

Switch typeManaged
Switch layerL3+
Quality of Service (QoS) supportYes
Web-based managementYes

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity24
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
Combo SFP ports quantity2
Fiber optic connectorSFP
Console portRJ-45
HDMI stacking ports2
Power connectorDC-in jack

Network

Networking standardsIEEE 802.1D, IEEE 802.1Q, IEEE 802.1x, IEEE 802.2, IEEE 802.3, IEEE 802.3ac, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G supportNo
IP routingYes
Auto MDI/MDI-XYes
VLAN supportYes

Data transmission

MAC address table16000 entries
Switching capacity18.8 Gbit/s
Throughput27.9 Mpps
Latency (10-100 Mbps)12 µs

Security

DHCP featuresDHCP server, DHCP client
Access Control List (ACL)Yes
IGMP snoopingYes
SSH/SSL supportYes
Security algorithmsLEAP, PEAP, SSH, SSL/TLS, WPA2-RADIUS

Multicast features

Multicast supportYes

Design

Rack mountingYes
Form factor1U
Product colourGrey
LED indicatorsYes

Power

AC input voltage100 - 240 V
AC input frequency47/63 Hz
Power consumption (typical)18.3 W

Power over Ethernet (PoE)

Power over Ethernet (PoE)No

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-25 - 70 °C
Operating relative humidity (H-H)5 - 90%
Storage relative humidity (H-H)5 - 95%
Operating altitude0 - 3048 m

Weight & dimensions

Width440 mm
Depth330 mm
Height203 mm
Weight2.2 kg
