Allied Telesis AT-8000S/16 Managed

Allied Telesis AT-8000S/16 Managed

Model AT-8000S/16Part no. AT-8000S/16-10EAN 7670351816228

38 specifications
  • Memory64 MB
  • Speed1 Gbit/s
  • ConnectivityWired
  • Weight1.95 kg
  • Switch typeManaged
  • Basic switching RJ-45 Ethernet ports quantity16
See all specifications

Overview

Memory
64 MB
Speed
1 Gbit/s
Connectivity
Wired
Weight
1.95 kg
Switch type
Managed
Basic switching RJ-45 Ethernet ports quantity
16
Brand
Allied Telesis
Model
AT-8000S/16
Part numbers
AT-8000S/16-10, AT-8000S/16-30
EAN / UPC
7670351816228, 5054484148319, 5054533148314, 7670351816600 +1 more
Also known as
Allied Telesis AT-8000S/16 Managed

Specifications

38 specifications in 13 groups

Management features

Switch typeManaged
Quality of Service (QoS) supportYes

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity16
Console portRS-232

Network

Networking standardsIEEE 802.1D, IEEE 802.1s, IEEE 802.1W, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z

Data transmission

MAC address table8000 entries
Switching capacity5.2 Gbit/s
Throughput3.87 Mpps
Maximum data transfer rate1 Gbit/s

Security

Access Control List (ACL)Yes
Security algorithmsSSH

Protocols

Management protocolsTelnet, HTTP, MIB, SNMP, CLI

Design

StackableNo
SafetyUL 1950 (UL/cUL), EN60950 (TUV)

Performance

Processor frequency400 MHz
Memory typeRAM
Internal memory64 MB
Flash memory16 MB
Mean time between failures (MTBF)447901.90 h

Power

Power sourceAC/DC
Power consumption (typical)30 W

Power over Ethernet (PoE)

Power over Ethernet (PoE)No

Other features

Data transfer rate10 Mbit/s
Dimensions (WxDxH)330 x 230.5 x 43.2 mm
Connectivity technologyWired
Authentication methodTACACS+, RADIUS
Networking featuresEthernet, Fast Ethernet
Packet transfer speed1488000 pps
Power requirements100-240V; 12V, 0.75A
Electromagnetic emissionsFCC Class A, EN55022 Class A, VCCI Class A, C-Tick, EN61000-3-2, EN61000-3-3
Electromagnetic immunityEN55024

Operational conditions

Operating temperature (T-T)0 - 45 °C
Storage temperature (T-T)-25 - 70 °C
Operating relative humidity (H-H)10 - 90%
Storage relative humidity (H-H)5 - 95%
Operating altitude0 - 3000 m
Heat dissipation102.45 BTU/h

Weight & dimensions

Weight1.95 kg
