Allied Telesis 12x 10/100/1000T Copper Ports & 4x1000X GBIC ports

Allied Telesis 12x 10/100/1000T Copper Ports & 4x1000X GBIC ports

Model 12x 10/100/1000T Copper Ports & 4x1000X GBIC portsPart no. AT-9812TEAN 767035152059

24 specifications
  • Speed1 Gbit/s
  • Weight6.26 kg
  • Basic switching RJ-45 Ethernet ports quantity12
  • Copper ethernet cabling technology1000Base-T, 100Base-T, 10Base-T
  • Switching capacity32 Gbit/s
  • Management protocolsSNMP, SMNP, VRRP, RMON, IGMP
See all specifications

Overview

Speed
1 Gbit/s
Weight
6.26 kg
Basic switching RJ-45 Ethernet ports quantity
12
Copper ethernet cabling technology
1000Base-T, 100Base-T, 10Base-T
Switching capacity
32 Gbit/s
Management protocols
SNMP, SMNP, VRRP, RMON, IGMP
Brand
Allied Telesis
Model
12x 10/100/1000T Copper Ports & 4x1000X GBIC ports
Part number
AT-9812T
EAN / UPC
767035152059
Also known as
Allied Telesis 12x 10/100/1000T Copper Ports & 4x1000X GBIC ports

Specifications

24 specifications in 10 groups

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity12

Network

Networking standardsIEEE 802.1D, IEEE 802.1Q, IEEE 802.1v, IEEE 802.1x, IEEE 802.2, IEEE 802.3ac, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Copper ethernet cabling technology1000Base-T, 100Base-T, 10Base-T
Full duplexYes

Data transmission

Switching capacity32 Gbit/s
Maximum data transfer rate1 Gbit/s

Protocols

Management protocolsSNMP, SMNP, VRRP, RMON, IGMP
Switching protocolsTCP, UDP, IARP, DVMRP, DHCP
Data link protocolsEthernet, Fast Ethernet, Gigabit Ethernet

Design

SafetyUL60950, CAN/CSA-C22.2

Performance

Mean time between failures (MTBF)480000 h

Power

Power consumption (typical)131 W

Other features

Data transfer rate1000 Mbit/s
Dimensions (WxDxH)440 x 360 x 66 mm
Power requirements100-240V, 50-60 Hz
Slot typeGBIC
Electromagnetic emissionsEN55022 Class B, FCC Class B, VCCI Class B
I/O ports12x 10/100/1000 Ethernet ports 4x GBIC slots 1x Power Adapter port
Technical featuresMIB Support IPv6 Support VLAN Support

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-25 - 75 °C
Operating relative humidity (H-H)5 - 95%
Heat dissipation448 BTU/h

Weight & dimensions

Weight6.26 kg
