NSG300 gateway/controller 10, 100, 1000 Mbit/s
Model NSG300Part no. NSG300-ZZ0102FEAN 4718937603633
38 specifications
- Memory4000 MB
- Weight3.3 kg
- LED indicatorsYes
- Control display unitNo
- Ethernet LAN data rates10,100,1000 Mbit/s
- USB 2.0 ports quantity2
Overview
- Memory
- 4000 MB
- Weight
- 3.3 kg
- LED indicators
- Yes
- Control display unit
- No
- Ethernet LAN data rates
- 10,100,1000 Mbit/s
- USB 2.0 ports quantity
- 2
- Brand
- Zyxel
- Category
- Gateways/Controllers
- Model
- NSG300
- Part number
- NSG300-ZZ0102F
- EAN / UPC
- 4718937603633
- Also known as
- Zyxel NSG300 gateway/controller 10, 100, 1000 Mbit/s
Specifications
38 specifications in 13 groups
Design
| Specification | Value |
|---|---|
| LED indicators | Yes |
Performance
| Specification | Value |
|---|---|
| Control display unit | No |
| Built-in processor | Yes |
| Internal memory | 4000 MB |
Data transmission
| Specification | Value |
|---|---|
| Static route | Yes |
Protocols
| Specification | Value |
|---|---|
| DHCP client | Yes |
| DHCP server | Yes |
Network
| Specification | Value |
|---|---|
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| VPN support | IPSec, L2TP over IPSec |
Security
| Specification | Value |
|---|---|
| Access Control List (ACL) | Yes |
| Security algorithms | 3DES, 256-bit AES, DES, MD5, SHA-1, SHA-2 |
| DoS attack prevention | Yes |
| Firewall security | Yes |
| VLAN support | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 2 |
| Number of console ports | 1 |
| Ethernet LAN (RJ-45) ports | 6 |
| WAN connection | Ethernet (RJ-45) |
Management features
| Specification | Value |
|---|---|
| Quality of Service (QoS) support | Yes |
| Syslog | Yes |
| Web-based management | Yes |
Power
| Specification | Value |
|---|---|
| Input voltage | 100-240 V |
| Output voltage | 50/60 V |
| Output current | 1.3 A |
| Heat dissipation | 199.61 BTU/h |
Weight & dimensions
| Specification | Value |
|---|---|
| Depth | 250 mm |
| Height | 44 mm |
| Width | 430 mm |
| Weight | 3.3 kg |
Packaging data
| Specification | Value |
|---|---|
| Package depth | 392 mm |
| Package height | 163 mm |
| Package width | 519 mm |
| Package weight | 4.8 kg |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -30 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 10 - 90% |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85176990 |
