Nuclias Cloud SD-WAN Gateway
Model DBG-2000EAN 790069459825
40 specifications
- Memory4096 MB
- Weight1.66 kg
- ColourWhite
- Mean time between failures (MTBF)610802 h
- Control display unitNo
- Ethernet LAN data rates10,100,1000 Mbit/s
Overview
- Memory
- 4096 MB
- Weight
- 1.66 kg
- Colour
- White
- Mean time between failures (MTBF)
- 610802 h
- Control display unit
- No
- Ethernet LAN data rates
- 10,100,1000 Mbit/s
- Brand
- D-Link
- Category
- Gateways/Controllers
- Model
- DBG-2000
- Part number
- DBG-2000
- EAN / UPC
- 790069459825, 790069462344, 790069462351
- Also known as
- D-Link Nuclias Cloud SD-WAN Gateway
Specifications
40 specifications in 12 groups
Design
| Specification | Value |
|---|---|
| Product colour | White |
| LED indicators | Power |
Features
| Specification | Value |
|---|---|
| Mean time between failures (MTBF) | 610802 h |
Performance
| Specification | Value |
|---|---|
| Control display unit | No |
| Internal memory | 4096 MB |
| Flash memory | 16 MB |
Network
| Specification | Value |
|---|---|
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Networking standards | IEEE 802.3ab, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x |
| Flow control support | Yes |
| Load balancing | Yes |
| Number of concurrent sessions (max) | 200000 |
| 3DES/AES throughput | 0.45 Gbit/s |
| Firewall throughput | 1800 Mbit/s |
| GRE VPN tunnels (max) | 200 |
| PPTP/L2TP VPN tunnels (max) | 200 |
| SSL VPN throughput | 0.2 Gbit/s |
| SSL VPN tunnels (max) | 200 |
| Sessions per second | 2000 |
Security
| Specification | Value |
|---|---|
| DoS attack prevention | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| USB 2.0 ports quantity | 1 |
| Console port | RJ-45 |
| Number of console ports | 1 |
| Ethernet LAN (RJ-45) ports | 4 |
Management features
| Specification | Value |
|---|---|
| Concurrent SSL VPN users (max) | 200 |
Power
| Specification | Value |
|---|---|
| Power consumption (max) | 20 W |
| Input voltage | 100 - 240 V |
| Input frequency | 50 - 60 Hz |
| Output voltage | 12 V |
Weight & dimensions
| Specification | Value |
|---|---|
| Depth | 215 mm |
| Height | 42 mm |
| Width | 135 mm |
| Weight | 1.66 kg |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 70 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Storage relative humidity (H-H) | 5 - 95% |
Sustainability
| Specification | Value |
|---|---|
| Sustainability compliance | Yes |
Certificates
| Specification | Value |
|---|---|
| Compliance certificates | CE, Low Voltage Directive (LVD) |
| Certification | FCC, IC, RCM, VCCI |
