525749 gateway/controller 10, 100, 1000 Mbit/s
Model 525749EAN 766623525749
39 specifications
- Memory256 MB
- Weight1.7 kg
- ColourBlack
- Built-in processorYes
- Ethernet LAN data rates10,100,1000 Mbit/s
- USB 2.0 ports quantity1
Overview
- Memory
- 256 MB
- Weight
- 1.7 kg
- Colour
- Black
- Built-in processor
- Yes
- Ethernet LAN data rates
- 10,100,1000 Mbit/s
- USB 2.0 ports quantity
- 1
- Brand
- Intellinet
- Category
- Gateways/Controllers
- Model
- 525749
- Part number
- 525749
- EAN / UPC
- 766623525749
- Also known as
- Intellinet 525749 gateway/controller 10, 100, 1000 Mbit/s
Specifications
39 specifications in 13 groups
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Mounting type | Rack mounting |
| LED indicators | Power |
Performance
| Specification | Value |
|---|---|
| Built-in processor | Yes |
| Processor frequency | 880 MHz |
| Number of processors installed | 1 |
| Internal memory | 256 MB |
| Internal memory type | DDR3 |
| Flash memory | 16 MB |
Protocols
| Specification | Value |
|---|---|
| DHCP client | Yes |
| DHCP server | Yes |
| DMZ support | Yes |
Network
| Specification | Value |
|---|---|
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Networking standards | IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u |
| Dynamic DNS (DDNS) | Yes |
Security
| Specification | Value |
|---|---|
| MAC address filtering | Yes |
| Security algorithms | SSH |
| Firewall security | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 4 |
| WAN connection | Ethernet (RJ-45) |
Management features
| Specification | Value |
|---|---|
| Quality of Service (QoS) support | Yes |
| Reset button | Yes |
| Syslog | Yes |
Power
| Specification | Value |
|---|---|
| Input voltage | 100 - 240 V |
| Input frequency | 50 - 60 Hz |
| Output voltage | 5 V |
| Output current | 2 A |
Weight & dimensions
| Specification | Value |
|---|---|
| Depth | 208 mm |
| Height | 44 mm |
| Width | 440 mm |
| Weight | 1.7 kg |
Packaging content
| Specification | Value |
|---|---|
| Cables included | AC |
| Manual | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
Certificates
| Specification | Value |
|---|---|
| Certification | FCC A, CE, RoHS |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85176990 |
