Omada 5G Outdoor Gateway
Model ER701-5G-OutdoorPart no. ER701-5G-OUTDOOREAN 840460600705
36 specifications
- Memory2048 MB
- ColourWhite
- Antenna typeInternal
- DHCP clientYes
- Ethernet LAN data rates10,100,1000,2500 Mbit/s
- Power consumption (max)15.3 W
Overview
- Memory
- 2048 MB
- Colour
- White
- Antenna type
- Internal
- DHCP client
- Yes
- Ethernet LAN data rates
- 10,100,1000,2500 Mbit/s
- Power consumption (max)
- 15.3 W
- Brand
- TP-Link
- Category
- Gateways/Controllers
- Model
- ER701-5G-Outdoor
- Part number
- ER701-5G-OUTDOOR
- EAN / UPC
- 840460600705, 1210002601412
- Also known as
- TP-Link Omada 5G Outdoor Gateway
Specifications
36 specifications in 10 groups
Design
| Specification | Value |
|---|---|
| Product colour | White |
| Mounting type | Wall mounting |
| LED indicators | Yes |
Features
| Specification | Value |
|---|---|
| Antenna type | Internal |
Performance
| Specification | Value |
|---|---|
| Internal memory | 2048 MB |
| Internal memory type | LPDDR4x |
| Flash memory | 4098 MB |
Protocols
| Specification | Value |
|---|---|
| DHCP client | Yes |
| DHCP server | Yes |
| Routing protocols | OSPF |
Network
| Specification | Value |
|---|---|
| Ethernet LAN data rates | 10,100,1000,2500 Mbit/s |
| Networking standards | IEEE 802.11g, IEEE 802.11n, IEEE 802.11b |
| Wi-Fi | Yes |
| WLAN data transfer rates supported | 150 Mbit/s |
| Mobile network generation | 5G |
| Data network | 5G, 4G, 3G, WCDMA |
| Number of concurrent sessions (max) | 500000 |
| Data transfer rate | 7.01 Gbit/s |
| Sessions per second | 6100 |
Security
| Specification | Value |
|---|---|
| Security algorithms | WPA, WPA2-Personal, SNMP, SNMPv2, SNMPv3 |
| Network address translation (NAT) | Yes |
| VLAN support | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| SIM card slot | Yes |
| SIM card type | NanoSIM |
| Number of simultaneous SIM cards | 2 |
| Ethernet LAN (RJ-45) ports | 1 |
Management features
| Specification | Value |
|---|---|
| Reset button | Yes |
| Syslog | Yes |
| Web-based management | Yes |
Power
| Specification | Value |
|---|---|
| Power consumption (max) | 15.3 W |
| Input voltage | 42 - 57 V |
| Input current | 0.375 - 0.6 A |
| Power over Ethernet (PoE) type supported | Passive PoE, PoE+ |
Weight & dimensions
| Specification | Value |
|---|---|
| Depth | 110 mm |
| Height | 36 mm |
| Width | 183 mm |
