DWC-2000 gateway/controller
Model DWC-2000EAN 790069403736
36 specifications
- Weight3.72 kg
- Management protocolsHTTP, SNMP v1, v2c, v3
- Data transfer rate1 Gbit/s
- Security algorithms802.1x RADIUS, WPA, WPA2
- USB 2.0 ports quantity2
- Power consumption (typical)26.95 W
Overview
- Weight
- 3.72 kg
- Management protocols
- HTTP, SNMP v1, v2c, v3
- Data transfer rate
- 1 Gbit/s
- Security algorithms
- 802.1x RADIUS, WPA, WPA2
- USB 2.0 ports quantity
- 2
- Power consumption (typical)
- 26.95 W
- Brand
- D-Link
- Category
- Gateways/Controllers
- Model
- DWC-2000
- Part number
- DWC-2000
- EAN / UPC
- 790069403736, 5054629821565, 7900694037364
- Also known as
- D-Link DWC-2000 gateway/controller
Specifications
36 specifications in 12 groups
Performance
| Specification | Value |
|---|---|
| Compatible products | DWL-8610AP, DWL-8600AP, DWL-6600AP, DWL-3600AP, DWL-2600AP |
Protocols
| Specification | Value |
|---|---|
| Management protocols | HTTP, SNMP v1, v2c, v3 |
Network
| Specification | Value |
|---|---|
| Data transfer rate | 1 Gbit/s |
Security
| Specification | Value |
|---|---|
| Security algorithms | 802.1x RADIUS, WPA, WPA2 |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 2 |
| Ethernet LAN (RJ-45) ports | 4 |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 26.95 W |
| Input voltage | 100 - 240 V |
| Input frequency | 50 - 60 Hz |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 3.72 kg |
| Dimensions (WxDxH) | 440 x 310 x 44 mm |
Packaging data
| Specification | Value |
|---|---|
| Package depth | 504 mm |
| Package height | 110 mm |
| Package width | 444 mm |
| Package weight | 5.85 kg |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 70 °C |
| Operating relative humidity (H-H) | 5 - 95% |
Technical details
| Specification | Value |
|---|---|
| Master (outer) cases per pallet (air) | 12 pc(s) |
| Master (outer) cases per pallet (sea) | 12 pc(s) |
| Pallet gross length | 110 cm |
| Pallet gross weight (air) | 250.6 kg |
| Pallet gross weight (sea) | 250.6 kg |
| Pallet gross width | 120 cm |
| Pallet height (air) | 109.5 cm |
| Pallet height (sea) | 2.06 m |
| Products per pallet (air) | 36 pc(s) |
| Products per pallet (sea) | 36 pc(s) |
| Products per shipping (inner) case | 3 pc(s) |
| Shipping (inner) case gross weight | 18.8 kg |
| Shipping (inner) case height | 48 cm |
| Shipping (inner) case length | 52.6 cm |
| Shipping (inner) case net weight | 17.5 kg |
| Shipping (inner) case width | 39.6 cm |
Certificates
| Specification | Value |
|---|---|
| Certification | FCC Class A, CE Class A, C-Tick, IC, cUL, LVD |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85176990 |
