MP-112 gateway/controller 10, 100 Mbit/s
Model MP-112Part no. MP112/2S/SIP/CEREAN 5715063384756
22 specifications
- Connectivity2 FXS
- Weight500 g
- ColourBlack
- Management protocolsWeb GUI, SSH/Telnet, SNMP v2/v3,
- Ethernet LAN data rates10,100 Mbit/s
- Security algorithmsHTTPS, SRTP, TLS
Overview
- Connectivity
- 2 FXS
- Weight
- 500 g
- Colour
- Black
- Management protocols
- Web GUI, SSH/Telnet, SNMP v2/v3,
- Ethernet LAN data rates
- 10,100 Mbit/s
- Security algorithms
- HTTPS, SRTP, TLS
- Brand
- AudioCodes
- Category
- Gateways/Controllers
- Model
- MP-112
- Part number
- MP112/2S/SIP/CER
- EAN / UPC
- 5715063384756
- Also known as
- AudioCodes MP-112 gateway/controller 10, 100 Mbit/s
Specifications
22 specifications in 9 groups
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| LED indicators | Yes |
Features
| Specification | Value |
|---|---|
| Voice codecs | G.711alaw, G.711ulaw, G.722, G.723.1, G.726, G.727, G.729A, G.729B |
Protocols
| Specification | Value |
|---|---|
| Management protocols | Web GUI, SSH/Telnet, SNMP v2/v3, |
| Supported network protocols | IPV4/IPV6, DiffServ, TOS |
| VoIP protocols | G.168 - 2004 |
| Supported protocols | RTP (RFC 3550), SRTP (RFC 3711), RTCP (RFC 3550), RTCP-XR (RFC 3611) , |
Network
| Specification | Value |
|---|---|
| Ethernet LAN data rates | 10,100 Mbit/s |
| Modulation | DTMF |
Security
| Specification | Value |
|---|---|
| Security algorithms | HTTPS, SRTP, TLS |
| VLAN support | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Interface | 2 FXS |
| Ethernet LAN (RJ-45) ports | 1 |
Power
| Specification | Value |
|---|---|
| Input voltage | 100 - 240 V |
| Input frequency | 50 - 60 Hz |
Weight & dimensions
| Specification | Value |
|---|---|
| Depth | 220 mm |
| Height | 42 mm |
| Width | 172 mm |
| Weight | 500 g |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 5 - 40 °C |
| Storage temperature (T-T) | -25 - 85 °C |
| Operating relative humidity (H-H) | 10 - 90% |
