Exos E 2U12
Model Exos E 2U12Part no. D4835X000000DA
29 specifications
- Weight26 kg
- ColourBlack, Metallic
- Storage drives installedNo
- Chassis typeRack (2U)
- Power supply unit (PSU) capacity580 W
- Width483 mm
Overview
- Weight
- 26 kg
- Colour
- Black, Metallic
- Storage drives installed
- No
- Chassis type
- Rack (2U)
- Power supply unit (PSU) capacity
- 580 W
- Width
- 483 mm
- Brand
- Seagate
- Category
- Disk Array
- Model
- Exos E 2U12
- Part number
- D4835X000000DA
- Also known as
- Seagate Exos E 2U12 disk array Rack (2U) Black, Metallic
Specifications
29 specifications in 6 groups
Storage
| Specification | Value |
|---|---|
| Storage drives installed | No |
| Installed storage drive type | No |
| Supported storage drive types | HDD & SSD |
| Number of storage drives supported | 12 |
| Storage drive interface | Serial Attached SCSI (SAS) |
| Storage drive size | 3.5" |
| Hot-swap drive bays | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| USB connectivity | No |
| Mini-SAS host port | Yes |
| Number of mini-SAS host ports | 3 |
| RJ-45 ports quantity | 2 |
| Remote management port | RJ-45 (Gigabit) |
| Serial interface type | RS-232 |
Design
| Specification | Value |
|---|---|
| Chassis type | Rack (2U) |
| Product colour | Black, Metallic |
| Cooling | Yes |
| Hot-swap fan module | Yes |
Power
| Specification | Value |
|---|---|
| Power supply unit (PSU) capacity | 580 W |
| Number of power supply units | 2 |
| AC input voltage | 90 - 264 V |
| AC input frequency | 50 - 60 Hz |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 483 mm |
| Depth | 630 mm |
| Height | 88.9 mm |
| Weight | 26 kg |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 5 - 40 °C |
| Operating relative humidity (H-H) | 10 - 80% |
| Storage temperature (T-T) | -40 - 70 °C |
| Storage relative humidity (H-H) | 5 - 100% |
