D16 Thunderbolt 3
Model D16 Thunderbolt 3Part no. D16-THUNDERBOLT3EAN 6939236140713
44 specifications
- Noise35 dB
- ColourBlack, Grey
- Storage drives installedNo
- Power supply unit (PSU) capacity550 W
- Mac compatibilityYes
- Width550 mm
Overview
- Noise
- 35 dB
- Colour
- Black, Grey
- Storage drives installed
- No
- Power supply unit (PSU) capacity
- 550 W
- Mac compatibility
- Yes
- Width
- 550 mm
- Brand
- TerraMaster
- Category
- Disk Array
- Model
- D16 Thunderbolt 3
- Part number
- D16-THUNDERBOLT3
- EAN / UPC
- 6939236140713, 6939236141659
- Also known as
- TerraMaster D16 Thunderbolt 3 disk array 0 TB Black, Grey
Specifications
44 specifications in 10 groups
Storage
| Specification | Value |
|---|---|
| Storage drives installed | No |
| Installed storage drive type | No |
| Number of storage drives installed | 0 |
| Total installed storage capacity | 0 TB |
| Supported storage drive types | HDD & SSD |
| Number of storage drives supported | 16 |
| Maximum supported storage capacity | 256 TB |
| Supported storage drive interfaces | Serial ATA |
| Storage drive sizes supported | 2.5,3.5" |
| RAID levels | 0, 1, 5, 10, 50, JBOD |
| Data transfer rate | 40 Gbit/s |
| Hot-swap drive bays | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| USB connectivity | No |
| Thunderbolt technology | Yes |
| Thunderbolt ports quantity | 2 |
| Thunderbolt version | 3 |
| DisplayPorts quantity | 1 |
| DisplayPort version | 1.2 |
Design
| Specification | Value |
|---|---|
| Product colour | Black, Grey |
| Noise level | 35 dB |
| Number of fans | 3 fan(s) |
| Fan diameter | 12 cm |
| Built-in display | No |
| Certification | CE, FCC, CCC, KC |
Power
| Specification | Value |
|---|---|
| Power supply unit (PSU) capacity | 550 W |
| Number of power supply units | 1 |
| Power consumption (typical) | 210 W |
| AC input voltage | 100-240 V |
| AC input frequency | 50 - 60 Hz |
System requirements
| Specification | Value |
|---|---|
| Mac compatibility | Yes |
| Mac operating systems supported | macOS |
| Windows operating systems supported | Yes |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 550 mm |
| Depth | 136 mm |
| Height | 440 mm |
Packaging data
| Specification | Value |
|---|---|
| Package width | 580 mm |
| Package depth | 270 mm |
| Package height | 710 mm |
Packaging content
| Specification | Value |
|---|---|
| Cables included | AC, Thunderbolt |
| Screws included | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 5 - 40 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Storage temperature (T-T) | -20 - 60 °C |
Other features
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
