D5-300C disk array
0 TB Desktop Black, Grey
Model D5-300CEAN 6939236139120
45 specifications
- Noise19.8 dB
- Weight2.1 kg
- ColourBlack, Grey
- Storage drives installedNo
- USB connectivityYes
- Device classHome & Home Office
Overview
- Noise
- 19.8 dB
- Weight
- 2.1 kg
- Colour
- Black, Grey
- Storage drives installed
- No
- USB connectivity
- Yes
- Device class
- Home & Home Office
- Brand
- TerraMaster
- Category
- Disk Array
- Model
- D5-300C
- Part number
- D5-300C
- EAN / UPC
- 6939236139120
- Also known as
- TerraMaster D5-300C disk array 0 TB Desktop Black, Grey
Specifications
45 specifications in 10 groups
Storage
| Specification | Value |
|---|---|
| Storage drives installed | No |
| Installed storage drive type | No |
| Number of storage drives installed | 0 |
| Total installed storage capacity | 0 TB |
| Supported storage drive types | HDD & SSD |
| Number of storage drives supported | 5 |
| Maximum supported storage capacity | 80 TB |
| Supported storage drive interfaces | Serial ATA |
| Storage drive sizes supported | 2.5,3.5" |
| RAID levels | 0, 1, JBOD |
| Data transfer rate | 5 Gbit/s |
| Hot-swap drive bays | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| USB connectivity | Yes |
Design
| Specification | Value |
|---|---|
| Device class | Home & Home Office |
| Chassis type | Desktop |
| Product colour | Black, Grey |
| LED indicators | HDD, Power |
| Noise level | 19.8 dB |
| Number of fans | 2 fan(s) |
| Fan diameter | 8 cm |
| Built-in display | No |
| Certification | CE, FCC, CCC, KC |
Power
| Specification | Value |
|---|---|
| Power supply unit (PSU) capacity | 90 W |
| Number of power supply units | 1 |
| AC input voltage | 100-240 V |
| AC input frequency | 50 - 60 Hz |
| DC output voltage | 12 V |
System requirements
| Specification | Value |
|---|---|
| Mac compatibility | Yes |
| Mac operating systems supported | macOS |
| Windows operating systems supported | Yes |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 225 mm |
| Depth | 136 mm |
| Height | 227 mm |
| Weight | 2.1 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 275 mm |
| Package depth | 186 mm |
| Package height | 300 mm |
| Package weight | 3.5 kg |
Packaging content
| Specification | Value |
|---|---|
| Cables included | AC |
| Number of adapters included | 1 pc(s) |
| Screws included | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 5 - 40 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Storage temperature (T-T) | -20 - 60 °C |
Other features
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
