Storage V3700 V2 XP
Model Storage V3700 V2 XPPart no. 6535EC3EAN 889488122790
39 specifications
- Weight26 kg
- ColourBlack, Silver
- Storage drives installedNo
- USB connectivityYes
- Device classLarge Enterprise Business
- Cache size (max)32 GB
Overview
- Weight
- 26 kg
- Colour
- Black, Silver
- Storage drives installed
- No
- USB connectivity
- Yes
- Device class
- Large Enterprise Business
- Cache size (max)
- 32 GB
- Brand
- Lenovo
- Category
- Disk Array
- Model
- Storage V3700 V2 XP
- Part numbers
- 6535EC3, 6535EC4
- EAN / UPC
- 889488122790, 889488418961, 889488418978
- Also known as
- Lenovo Storage V3700 V2 XP disk array 0 TB Rack (2U) Black, Silver
Specifications
39 specifications in 8 groups
Storage
| Specification | Value |
|---|---|
| Storage drives installed | No |
| Installed storage drive type | No |
| Number of storage drives installed | 0 |
| Total installed storage capacity | 0 TB |
| Supported storage drive types | HDD |
| Number of storage drives supported | 12 |
| Storage drive interface | Serial Attached SCSI (SAS) |
| Storage drive size | 3.5" |
| RAID levels | 0, 1, 5, 6, 10 |
| Hot-swap drive bays | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| USB connectivity | Yes |
| Host ports | 6 |
| Number of SAS host ports | 6 |
| RJ-45 ports quantity | 4 |
| Remote management port | RJ-45 (Gigabit) |
| SAS host port | Yes |
Design
| Specification | Value |
|---|---|
| Device class | Large Enterprise Business |
| Chassis type | Rack (2U) |
| Product colour | Black, Silver |
| LED indicators | Yes |
| Redundant fans support | Yes |
| Supported network protocols | iSCSI |
Performance
| Specification | Value |
|---|---|
| Cache size (max) | 32 GB |
Power
| Specification | Value |
|---|---|
| Power supply unit (PSU) capacity | 800 W |
| Number of power supply units | 2 |
| Redundant power supply (RPS) support | Yes |
| Power consumption (typical) | 333 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 483 mm |
| Depth | 556 mm |
| Height | 87 mm |
| Weight | 26 kg |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 10 - 35 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage temperature (T-T) | -10 - 50 °C |
| Storage relative humidity (H-H) | 8 - 80% |
| Operating altitude | 0 - 3050 m |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 84717020 |
