SC7020 disk array
6.72 TB Rack (3U) Black, Silver
Model SC7020Part no. SC7020_AEAN 5397184362983
29 specifications
- Weight15.2 kg
- ColourBlack, Silver
- Storage drives installedYes
- USB connectivityNo
- Device classLarge Enterprise Business
- Power supply unit (PSU) capacity1485 W
Overview
- Weight
- 15.2 kg
- Colour
- Black, Silver
- Storage drives installed
- Yes
- USB connectivity
- No
- Device class
- Large Enterprise Business
- Power supply unit (PSU) capacity
- 1485 W
- Brand
- Dell
- Category
- Disk Array
- Model
- SC7020
- Part numbers
- SC7020_A, 7020-2983
- EAN / UPC
- 5397184362983
- Also known as
- DELL SC7020 disk array 6.72 TB Rack (3U) Black, Silver
Specifications
29 specifications in 7 groups
Storage
| Specification | Value |
|---|---|
| Storage drives installed | Yes |
| Installed storage drive type | SSD |
| Number of storage drives installed | 7 |
| Total installed storage capacity | 6.72 TB |
| Supported storage drive types | HDD & SSD |
| Number of storage drives supported | 30 |
| Storage drive capacity | 960 GB |
| Storage drive interface | Serial Attached SCSI (SAS) |
| Supported storage drive interfaces | SAS |
| RAID levels | 0, 1, 5, 6, 10 |
Ports & interfaces
| Specification | Value |
|---|---|
| USB connectivity | No |
Design
| Specification | Value |
|---|---|
| Device class | Large Enterprise Business |
| Chassis type | Rack (3U) |
| Product colour | Black, Silver |
| Supported network protocols | FC, iSCSI, 12Gb SAS |
Power
| Specification | Value |
|---|---|
| Power supply unit (PSU) capacity | 1485 W |
| Number of power supply units | 2 |
| Redundant power supply (RPS) support | Yes |
| AC input voltage | 200 - 240 V |
| AC input frequency | 50 - 60 Hz |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 445 mm |
| Depth | 785 mm |
| Height | 133.3 mm |
| Weight | 15.2 kg |
Packaging content
| Specification | Value |
|---|---|
| Cables included | AC |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 10 - 35 °C |
| Operating relative humidity (H-H) | -40 - 65% |
| Storage temperature (T-T) | 10 - 80 °C |
| Storage relative humidity (H-H) | 5 - 95% |
