PowerVault ME412 disk array
4.8 TB Rack (2U) Black
Model ME412Part no. ME412-FY25Q2EAN 884116486398
30 specifications
- ColourBlack
- Storage drives installedYes
- Device classLarge Enterprise Business
- Bytes per sector512e
- Power supply unit (PSU) capacity580 W
- Width483 mm
Overview
- Colour
- Black
- Storage drives installed
- Yes
- Device class
- Large Enterprise Business
- Bytes per sector
- 512e
- Power supply unit (PSU) capacity
- 580 W
- Width
- 483 mm
- Brand
- Dell
- Category
- Disk Array
- Model
- ME412
- Part numbers
- ME412-FY25Q2, ME412-FY25Q4, ME412-FY26Q2, ME412_263
- EAN / UPC
- 884116486398, 884116466789, 884116485414
- Also known as
- DELL PowerVault ME412 disk array 4.8 TB Rack (2U) Black
Specifications
30 specifications in 7 groups
Storage
| Specification | Value |
|---|---|
| Storage drives installed | Yes |
| Installed storage drive type | HDD |
| Number of storage drives installed | 2 |
| Total installed storage capacity | 4.8 TB |
| Supported storage drive types | HDD & SSD |
| Number of storage drives supported | 12 |
| Storage drive capacity | 2.4 TB |
| Storage drive interface | Serial Attached SCSI (SAS) |
| Storage drive size | 3.5" |
| Supported storage drive interfaces | SAS, Serial ATA III |
| Storage drive sizes supported | 3.5" |
| Data transfer rate | 12 Gbit/s |
Design
| Specification | Value |
|---|---|
| Device class | Large Enterprise Business |
| Chassis type | Rack (2U) |
| Product colour | Black |
| LED indicators | Yes |
Performance
| Specification | Value |
|---|---|
| Bytes per sector | 512e |
Power
| Specification | Value |
|---|---|
| Power supply unit (PSU) capacity | 580 W |
| Redundant power supply (RPS) support | Yes |
| AC input voltage | 250 V |
| AC input frequency | 50 - 60 Hz |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 483 mm |
| Depth | 602.9 mm |
| Height | 87.9 mm |
Packaging content
| Specification | Value |
|---|---|
| Cables included | AC |
| Packaging content | 24Gb HD-Mini SAS4 Cable, 1m, Quantity 4 |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 5 - 35 °C |
| Operating relative humidity (H-H) | 10 - 80% |
| Storage temperature (T-T) | -40 - 65 °C |
| Storage relative humidity (H-H) | 5 - 95% |
