PowerVault MD3800f disk array
3.6 TB Rack (2U) Grey
Model MD3800fPart no. 3800-8851EAN 5397063982790
24 specifications
- Weight29.3 kg
- ColourGrey
- Storage drives installedYes
- Device classLarge Enterprise Business
- Width446.3 mm
- Operating temperature (T-T)10 - 35 °C
Overview
- Weight
- 29.3 kg
- Colour
- Grey
- Storage drives installed
- Yes
- Device class
- Large Enterprise Business
- Width
- 446.3 mm
- Operating temperature (T-T)
- 10 - 35 °C
- Brand
- Dell
- Category
- Disk Array
- Model
- MD3800f
- Part numbers
- 3800-8851, 3800-0602, 3800-2790
- EAN / UPC
- 5397063982790, 5397063698851, 5397063830602
- Also known as
- DELL PowerVault MD3800f disk array 3.6 TB Rack (2U) Grey
Specifications
24 specifications in 5 groups
Storage
| Specification | Value |
|---|---|
| Storage drives installed | Yes |
| Installed storage drive type | HDD |
| Number of storage drives installed | 6 |
| Total installed storage capacity | 3.6 TB |
| Supported storage drive types | HDD & SSD |
| Number of storage drives supported | 12 |
| Maximum supported storage capacity | 48 TB |
| Storage drive capacity | 600 GB |
| Storage drive interface | Serial Attached SCSI (SAS) |
| Storage drive size | 3.5" |
| RAID levels | 0, 1, 5, 6, 10 |
| Data transfer rate | 16 Gbit/s |
| HDD speed | 15000 RPM |
Ports & interfaces
| Specification | Value |
|---|---|
| Fibre Channel | Yes |
Design
| Specification | Value |
|---|---|
| Device class | Large Enterprise Business |
| Chassis type | Rack (2U) |
| Product colour | Grey |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 446.3 mm |
| Depth | 561 mm |
| Height | 86.8 mm |
| Weight | 29.3 kg |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 10 - 35 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Operating altitude | -16 - 3048 m |
