Dell PowerVault MD3620f disk array
0.6 TB Rack (2U) Black
Model MD3620fPart no. 3620-2012EAN 5397063421992
32 specifications
- Weight24.2 kg
- ColourBlack
- Storage drives installedYes
- Chassis typeRack (2U)
- Power supply unit (PSU) capacity600 W
- Width446.3 mm
Overview
- Weight
- 24.2 kg
- Colour
- Black
- Storage drives installed
- Yes
- Chassis type
- Rack (2U)
- Power supply unit (PSU) capacity
- 600 W
- Width
- 446.3 mm
- Brand
- Dell
- Category
- Disk Array
- Model
- MD3620f
- Part numbers
- 3620-2012, 3620-2005, 3620-1992
- EAN / UPC
- 5397063421992, 5397063422012, 5397063422005
- Also known as
- DELL PowerVault MD3620f disk array 0.6 TB Rack (2U) Black
Specifications
32 specifications in 7 groups
Storage
| Specification | Value |
|---|---|
| Storage drives installed | Yes |
| Installed storage drive type | HDD |
| Number of storage drives installed | 2 |
| Total installed storage capacity | 0.6 TB |
| Supported storage drive types | HDD & SSD |
| Number of storage drives supported | 24 |
| Maximum supported storage capacity | 38.4 TB |
| Storage drive capacity | 300 GB |
| Storage drive interface | Serial Attached SCSI (SAS) |
| Storage drive size | 2.5" |
| RAID levels | 0, 1, 5, 6, 10 |
| Data transfer rate | 8 Gbit/s |
| Hot-swap drive bays | Yes |
| HDD speed | 10000 RPM |
Ports & interfaces
| Specification | Value |
|---|---|
| Fibre Channel | Yes |
Design
| Specification | Value |
|---|---|
| Chassis type | Rack (2U) |
| Product colour | Black |
Power
| Specification | Value |
|---|---|
| Power supply unit (PSU) capacity | 600 W |
| Redundant power supply (RPS) support | Yes |
| AC input voltage | 100-240 V |
| AC input frequency | 50 - 60 Hz |
System requirements
| Specification | Value |
|---|---|
| Linux operating systems supported | Yes |
| Windows operating systems supported | Yes |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 446.3 mm |
| Depth | 508 mm |
| Height | 86.8 mm |
| Weight | 24.2 kg |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 10 - 35 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage temperature (T-T) | -5 - 45 °C |
| Storage relative humidity (H-H) | 5 - 90% |
| Operating altitude | -16 - 3048 m |
