Data Domain DD9800
Model Data Domain DD9800Part no. DD9800-CTL
33 specifications
- Noise56.4 dB
- Weight53.2 kg
- ColourBlack
- Storage drives installedNo
- USB connectivityYes
- Device classLarge Enterprise Business
Overview
- Noise
- 56.4 dB
- Weight
- 53.2 kg
- Colour
- Black
- Storage drives installed
- No
- USB connectivity
- Yes
- Device class
- Large Enterprise Business
- Brand
- Dell
- Category
- Disk Array
- Model
- Data Domain DD9800
- Part number
- DD9800-CTL
- Also known as
- DELL Data Domain DD9800 disk array 0 TB Rack (4U) Black
Specifications
33 specifications in 7 groups
Storage
| Specification | Value |
|---|---|
| Storage drives installed | No |
| Installed storage drive type | No |
| Number of storage drives installed | 0 |
| Total installed storage capacity | 0 TB |
| Supported storage drive types | SSD |
| Maximum supported storage capacity | 630 TB |
| Storage drive interface | Serial ATA |
| Supported storage drive interfaces | SAS, Serial ATA |
| Storage drive sizes supported | 2.5" |
Ports & interfaces
| Specification | Value |
|---|---|
| USB connectivity | Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 6 |
| RJ-45 ports quantity | 4 |
| Serial interface type | RJ-45 |
Design
| Specification | Value |
|---|---|
| Device class | Large Enterprise Business |
| Chassis type | Rack (4U) |
| Product colour | Black |
| Noise level | 56.4 dB |
| Number of fans | 8 fan(s) |
| Redundant fans support | Yes |
Power
| Specification | Value |
|---|---|
| Power supply unit (PSU) capacity | 1887 W |
| Number of power supply units | 4 |
| Redundant power supply (RPS) support | Yes |
| Hot-swap PSU | Yes |
| AC input voltage | 200 - 240 V |
| AC input frequency | 50 - 60 Hz |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 483 mm |
| Depth | 749 mm |
| Height | 178 mm |
| Weight | 53.2 kg |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 10 - 35 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage temperature (T-T) | -40 - 65 °C |
Other features
| Specification | Value |
|---|---|
| Maximum internal memory | 256 GB |
