Compellent SC420
Model Compellent SC420Part no. SC420_AEAN 5397184363010
33 specifications
- Weight8.8 kg
- Storage drives installedYes
- Chassis typeRack (2U)
- Power supply unit (PSU) capacity600 W
- Width482 mm
- Operating temperature (T-T)10 - 35 °C
Overview
- Weight
- 8.8 kg
- Storage drives installed
- Yes
- Chassis type
- Rack (2U)
- Power supply unit (PSU) capacity
- 600 W
- Width
- 482 mm
- Operating temperature (T-T)
- 10 - 35 °C
- Brand
- Dell
- Category
- Disk Array
- Model
- Compellent SC420
- Part numbers
- SC420_A, 420-3010
- EAN / UPC
- 5397184363010
- Also known as
- DELL Compellent SC420 disk array 12.6 TB Rack (2U)
Specifications
33 specifications in 6 groups
Storage
| Specification | Value |
|---|---|
| Storage drives installed | Yes |
| Installed storage drive type | HDD |
| Number of storage drives installed | 7 |
| Total installed storage capacity | 12.6 TB |
| Supported storage drive types | HDD |
| Number of storage drives supported | 24 |
| Storage drive capacity | 1.8 TB |
| Storage drive interface | Serial Attached SCSI (SAS) |
| Storage drive size | 2.5" |
| Supported storage drive interfaces | SAS |
| Storage drive sizes supported | 2.5" |
| Hot-Plug support | Yes |
| HDD speed | 10000 RPM |
Design
| Specification | Value |
|---|---|
| Chassis type | Rack (2U) |
| LED indicators | Yes |
| Rack rails | Yes |
| Bezel | Yes |
Power
| Specification | Value |
|---|---|
| Power supply unit (PSU) capacity | 600 W |
| Number of power supply units | 2 |
| Redundant power supply (RPS) support | Yes |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 482 mm |
| Depth | 541 mm |
| Height | 87 mm |
| Weight | 8.8 kg |
Packaging content
| Specification | Value |
|---|---|
| Cables included | AC |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 10 - 35 °C |
| Operating relative humidity (H-H) | 8 - 85% |
| Storage temperature (T-T) | -40 - 65 °C |
| Storage relative humidity (H-H) | 5 - 95% |
| Operating altitude | -16 - 3048 m |
| Non-operating altitude | -16 - 10600 m |
